Product Model
FLKM-2FLK50/AI/S7-331/PLC
Selling Points
- 1Ensures reliable operation with a redundant system connector (FLK) for added reliability.
- 2Specifically designed for Siemens SIMATIC S7-300, ensuring compatibility and ease of integration.
- 3Features numerical labeling (1 - 40) for easy identification and configuration.
- 4Operates within a wide ambient temperature range of -20 °C to 50 °C, suitable for various industrial environments.
- 5Easy installation with screw connections, providing a secure and durable connection method.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Interface module | Insulation | Functional insulation |
Overvoltage category | II | Pollution degree | 2 |
Nominal voltage U | < 50 V DC
< 25 V AC | Max. current carrying capacity per branch | 0.5 A |
Max. total current of voltage supply | 1 A (per byte) | Rated insulation voltage | 50 V |
Rated surge voltage | 0.5 kV (1.2/50 μs) | Suitable I/O card | 6AG1331-7NF00-2AB0 |
Connection method | Screw connection | Number of positions | 40 |
Conductor cross section rigid | 0.2 mm² ... 4 mm² | Conductor cross section flexible | 0.2 mm² ... 2.5 mm² |
Conductor cross section AWG | 24 ... 12 | Connection method | IDC/FLK pin strip |
Number of connections | 2 | Number of positions | 50 |
Pitch | 2.54 mm | Status display present | No |
Width | 90 mm | Height | 77 mm |
Depth | 72 mm | Color | green (RAL 6021) |
Housing insulation material | PVC | Degree of protection | IP00 |
Degree of protection (Installation location) | ≥ IP54 (Installation location) | Ambient temperature (operation) | -20 °C ... 50 °C |
Altitude | < 2000 m | Standards/regulations | DIN EN 50178: 1998-04 |
Mounting type | DIN rail mounting | Assembly note | in rows with zero spacing |
Mounting position | any | Notes on operation | For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. |
Specifications may be subject to change without notice
