Product Model
FLKM 4-I/O-G4
Selling Points
- 1Versatile Compatibility - Accepts Opto 22 G4 or Grayhill G5 solid-state relays.
- 2High Reliability - Includes fuse and status indicator for reliable operation.
- 3Flexible Mounting - Can be fitted with solid-state relays or I/O modules, suitable for various mounting positions.
- 4Technical Specifications - Dimensions: 67.5 mm x 77 mm x 42 mm; Operating temperature: -20 °C to 55 °C.
- 5Durable Construction - Made with PVC and PA non-reinforced housing insulation material for long-term use in industrial environments.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Multi-channel solid-state relay module | No. of channels | 4 |
Compatible components | Digital I/O modules | With components | no |
Article revision | 04 | Input voltage range | 4 V DC ... 32 V DC |
Typical input current at U | 30 mA (Optocoupler dependent) | Compatible components | Digital I/O modules |
Limiting continuous current | 4 A | Error detection (line break / short-circuit) | no |
Connection method | Screw connection | Stripping length | 7 mm |
Screw thread | M3 | Number of connections | 1 |
Conductor cross section rigid | 0.14 mm² ... 2.5 mm² | Conductor cross section flexible | 0.14 mm² ... 1.5 mm² |
Conductor cross section AWG | 24 ... 14 | Width | 67.5 mm |
Height | 77 mm | Depth | 42 mm |
Color | green (RAL 6021) | Housing insulation material | PVC, side panel PA non-reinforced, |
Ambient temperature (operation) | -20 °C ... 55 °C | Ambient temperature (storage/transport) | -20 °C ... 70 °C |
Assembly note | in rows with zero spacing | Mounting position | any |
Specifications may be subject to change without notice
