Product Model
FLKM 50-PA/GE
Selling Points
- 1Connects up to 32 channels for GE-FANUC series 90-70.
- 2Digital input and output capabilities for versatile applications.
- 3High-quality insulation with overvoltage category II and pollution degree 2.
- 4Flexible conductor cross-section (0.14 mm² to 1.5 mm²) for various wiring needs.
- 5Operates within -20 °C to 50 °C ambient temperature, ensuring reliable performance in diverse environments.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Front adapter | Overvoltage category | II |
Pollution degree | 2 | Max. permissible operating voltage | < 50 V AC
60 V DC |
Max. permissible current | 1 A (per path) | Max. permissible total current | 2 A (per Byte, for supply via connector) |
Connection method | IDC/FLK pin strip | Number of connections | 1 |
Number of positions | 50 | Pitch | 2.54 mm |
Connection method | Screw connection | Conductor cross section rigid | 0.14 mm² ... 1.5 mm² |
Conductor cross section flexible | 0.14 mm² ... 1.5 mm² | Conductor cross section AWG | 28 ... 16 |
Ambient temperature (operation) | -20 °C ... 50 °C | Ambient temperature (storage/transport) | -20 °C ... 70 °C |
Standards/regulations | IEC 60664
IEC 60664A
DIN VDE 0110
DIN VDE 0160 (in parts) | Mounting position | any |
Notes on operation | For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. |
Specifications may be subject to change without notice
