Product Model
FLKM 64/LA
Selling Points
- 1Reliable Automation Solution: The Phoenix Contact FLKM 64/LA interface module ensures seamless integration with PLC systems, enhancing overall system reliability.
- 2High Position Count: With 64 positions, this module offers extensive connectivity options, making it versatile for various automation applications.
- 3II Overvoltage Category: Designed to withstand II overvoltage category, this module provides robust protection against electrical surges and spikes.
- 4Efficient Design: Optimized for efficient operation, the FLKM 64/LA reduces downtime and improves overall system performance.
- 5Versatile Application: Suitable for a wide range of automation tasks, from industrial control to process automation, ensuring flexibility in system design.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Interface module | Product family | VARIOFACE |
Number of positions | 64 | Overvoltage category | II |
Pollution degree | 2 | Nominal voltage U | 24 V DC |
Max. current carrying capacity per branch | 1 A | Connection in acc. with standard | IEC / EN |
Connection method | Screw connection | Stripping length | 8 mm |
Screw thread | M3 | Conductor cross section rigid | 0.2 mm² ... 4 mm² |
Conductor cross section flexible | 0.2 mm² ... 2.5 mm² | Conductor cross section AWG | 24 ... 12 |
Connection method | IDC/FLK pin strip | Number of positions | 64 |
Pitch | 2.54 mm | Status display | LED |
Status display present | Yes | Width | 180 mm |
Height | 58.5 mm | Depth | 77 mm |
Color | green (RAL 6021) | Housing insulation material | Polyamide 6.6 green |
Ambient temperature (operation) | -20 °C ... 50 °C | Ambient temperature (storage/transport) | -20 °C ... 70 °C |
Standards/regulations | IEC 60664
DIN EN 50178 | Mounting position | any |
Notes on operation | For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. |
Specifications may be subject to change without notice
