Product Model
FLKM-D15 SUB/S/LA
Selling Points
- 1Mounts seamlessly on NS 35/7.5 or NS 32 DIN rails for easy integration into your system.
- 2Supports a wide range of conductor sizes from 0.2 to 4 mm² (solid) and 0.2 to 2.5 mm² (stranded).
- 3Equipped with a light indicator for easy status monitoring, ensuring you're always informed.
- 4Operates within -20°C to +50°C, making it suitable for various environmental conditions.
- 5Meets IEC 60664, DIN EN 50178, and IEC 62103 standards for reliability and safety.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Interface module | Product family | VARIOFACE |
Number of positions | 15 | Overvoltage category | II |
Pollution degree | 2 | Nominal voltage U | 24 V DC |
Max. current carrying capacity per branch | 2.5 A | Connection in acc. with standard | IEC / EN |
Connection method | Screw connection | Stripping length | 8 mm |
Screw thread | M3 | Conductor cross section rigid | 0.2 mm² ... 4 mm² |
Conductor cross section flexible | 0.2 mm² ... 2.5 mm² | Conductor cross section AWG | 24 ... 12 |
Connection method | D-SUB pin strip | Number of positions | 15 |
Status display | LED | Status display present | Yes |
Width | 67.5 mm | Height | 58.5 mm |
Depth | 77 mm | Color | green (RAL 6021) |
Housing insulation material | Polyamide 6 green | Ambient temperature (operation) | -20 °C ... 50 °C |
Ambient temperature (storage/transport) | -20 °C ... 70 °C | Standards/regulations | IEC 60664
DIN EN 50178 |
Mounting position | any | Notes on operation | For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. |
Specifications may be subject to change without notice
