Product Model
FLKM HDSUB-26/F
Selling Points
- 1High-Density Sub-D Interface: Connects devices with precision and reliability.
- 2Compact Design: Space-efficient for easy integration into various systems.
- 3Durable Construction: Built to withstand harsh industrial environments.
- 430-Day Warranty: Ensures peace of mind with a comprehensive warranty.
- 5Versatile Compatibility: Compatible with a wide range of third-party products.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Interface module | Number of positions | 26 |
Nominal voltage U | 125 V | Max. current carrying capacity per branch | 1 A |
Connection in acc. with standard | IEC / EN | Connection method | Screw connection |
Stripping length | 8 mm | Screw thread | M3 |
Number of positions | 26 | Conductor cross section rigid | 0.2 mm² ... 4 mm² |
Conductor cross section flexible | 0.2 mm² ... 2.5 mm² | Conductor cross section AWG | 24 ... 12 |
Connection method | D-SUB socket strip | Number of positions | 26 |
Status display present | No | Width | 79 mm |
Height | 77 mm | Depth | 58 mm |
Color | green (RAL 6021) | Housing insulation material | Polyamide PA non-reinforced |
Ambient temperature (operation) | -20 °C ... 50 °C | Ambient temperature (storage/transport) | -20 °C ... 70 °C |
Mounting position | any | Notes on operation | For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. |
Specifications may be subject to change without notice
