Product Model
FLKMS 16
Selling Points
- 1Highly Reliable Connectivity: Ensures stable communication in industrial environments.
- 2Functional Insulation: Provides air clearances and creepage distances for enhanced safety.
- 3Overvoltage Category II: Protects against high voltage surges, ensuring module integrity.
- 4Easy Installation: Mounts on NS 32 or NS 35/7.5 DIN rails with screw connection.
- 5Versatile Applications: Suitable for various industrial applications with 16 positions.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Interface module | Product family | VARIOFACE |
Number of positions | 16 | Nominal voltage U | < 50 V AC
60 V DC |
Max. current carrying capacity per branch | 1 A | Connection in acc. with standard | IEC / EN |
Connection method | Screw connection | Stripping length | 8 mm |
Screw thread | M3 | Conductor cross section rigid | 0.2 mm² ... 4 mm² |
Conductor cross section flexible | 0.2 mm² ... 2.5 mm² | Conductor cross section AWG | 24 ... 12 |
Connection method | IDC/FLK pin strip | Number of positions | 16 |
Pitch | 2.54 mm | Status display present | No |
Width | 45 mm | Height | 72 mm |
Depth | 77 mm | Color | green (RAL 6021) |
Housing insulation material | Polyamide 6.6 green | Ambient temperature (operation) | -20 °C ... 50 °C |
Ambient temperature (storage/transport) | -20 °C ... 70 °C | Standards/regulations | IEC 60664
DIN EN 50178 |
Mounting type | DIN rail mounting | Mounting position | any |
Notes on operation | For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. |
Specifications may be subject to change without notice
