Phoenix Contact FL SWITCH 2408 - Industrial Ethernet Switch

Selling Points

1Suitable for PROFINET and EtherNet/IP networks: Supports both PROFINET and EtherNet/IP networks for seamless integration into industrial automation systems.
2Easy and Fast Startup: Quick and effortless commissioning with the FL NETWORK MANAGER software, reducing setup time and increasing productivity.
3Configuration Memory: Stores configuration settings for easy recall and management, ensuring consistent network performance.
4Advanced Management Features: Includes RSTP, DHCP client/server, VLANs, MRP, web-based management, and SNMP for comprehensive network control.
5Durable Construction: Built with stainless steel housing material (1.4301) for long-lasting performance in demanding environments.

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

Parameter	Value	Parameter	Value
Width	128 mm	Height	113 mm
Depth	67 mm	General	Support by phone or on-site (fee is charged)
Note on application	Only for industrial use	Material base plate	Die-cast aluminum, corrosion-resistant
Housing material	Stainless steel 1.4301	Mounting type	DIN rail mounting
Connection method	RJ45	Note on the connection method	Auto negotiation and autocrossing
Transmission speed	10/100 Mbps	Transmission physics	Copper
Transmission length	100 m (per segment)	Signal LEDs	Data receive, link status
No. of channels	8 (RJ45 ports)	Product type	Switch
Product family	Managed Switch 2000	Type	Block design
MTTF	357.82 Years (SN 29500 standard, temperature 25°C, operating cycle 21%) 191.24 Years (SN 29500 standard, temperature 40°C, operating cycle 34.25%) 25.65 Years (SN 29500 standard, temperature 70°C, operating cycle 100%)	Special properties	Extended temperature range Development process certified in accordance with IEC 62443-4-1 Compatible with IEC 62443-4-2
Signal delay	≥ 6.5 µs (Store and Forward mode, 10/100 Mbps, depending on the frame size)	Article revision	05
Protection class	III (VDE 0106)	Degree of pollution	2
Diagnostic functions	RMON History LLDP (Link Layer Discovery Protocol) SNMP-Traps N:1-Portmirroring ACD (Address Conflict Detection) SysLog CRC-Surveillance	Basic functions	Store-and-forward switch, complies with IEEE 802.3
Signal contact control voltage	typ. 24 V DC	PROFINET conformance class	Conformance-Class B
PROFINET device function	PROFINET device Fast Startup	Filter functions	Quality of Service (8 priority classes) Class of Service DiffServ/DSCP Port-Priorisierung VLAN (up to 32 VLANs) IGMP Snooping/Querier (v1/v2) Auto-Query-Port Extended Multicast Filtering
IP parameterization	DHCP client DHCP Option 82 (Relay Agent) DHCP server (pool-based, port-based) BootP DCP (Discovery and Configuration Protocol)	MAC address table	8k
Management	Web-based management (HTTP/HTTPS) Role-based user management (LDAP, RADIUS) SNMPv1/v2/v3 Command Line Interface (Telnet, SSH)	Redundancy	MRP (Media Redundancy Protocol) RSTP (Rapid Spanning Tree Protocol) FRD (Fast Ring Detection) Large Tree Support LACP (Link Aggregation Control Protocol) PROFINET S2 system redundancy
Status and diagnostic indicators	LEDs: US1, US2 (power supply), Fail (alarm contact), 2 LEDs per Ethernet port (Link/Activity and Speed)	Additional functions	Transmission of MMS and GOOSE (IEC 61850-8-1) Transmission of Modbus/TCP
Time synchronization	SNTP (Simple Network Time Protocol)	Port security	MAC-based, RADIUS (IEEE 802.1X), MAC Authentication Bypass
Basic functions	Store-and-forward switch, complies with IEEE 802.3	Local diagnostics	US1/2 Supply voltage US1, US2 Green LED FAIL Div. LED red LNK/ACT Link status Green LED SPD Data transmission speed Green LED
Maximum power dissipation for nominal condition	4.13 W (US = max, Tamb = max)	Test voltage	500 V DC
Test section	500 V DC 1 min	Transmission medium	Copper
Supply voltage (DC)	24 V DC (redundant)	Supply voltage range	19.2 V DC ... 32 V DC
Power supply connection	Via COMBICON, max. conductor cross section 2.5 mm²	Residual ripple	3.6 V
Max. current consumption	220 mA (U	Typical current consumption	160 mA (at U
Signal contact control voltage	typ. 24 V DC	Connection method	Push-in spring connection
Note on the connection method	Use only copper connecting cables providing the permitted temperature range (-40 °C ... 75 °C).	Conductor cross section, rigid	0.2 mm² ... 1.5 mm²
Conductor cross section, flexible	0.2 mm² ... 2.5 mm²	Conductor cross section AWG	24 ... 16
Stripping length	10 mm	Degree of protection	IP20
Ambient temperature (operation)	-40 °C ... 70 °C	Ambient temperature (storage/transport)	-40 °C ... 85 °C
Permissible humidity (operation)	10 % ... 95 % (non-condensing)	Permissible humidity (storage/transport)	10 % ... 95 % (non-condensing)
Shock (operation)	30g (EN 60068-2-27)	Vibration (operation)	in acc. with IEC 60068-2-6: 5g, 150 Hz
Air pressure (operation)	79 kPa ... 108 kPa up to 2000 m above mean sea level (Without derating)	Air pressure (storage/transport)	79 kPa ... 108 kPa up to 2000 m above mean sea level (Without derating)
Free from substances that could impair the application of coating	Yes	Identification	cULus
Identification	ISA S71.04.2013 G3 Harsh Group A	Temperature	B
Humidity	B	Vibration	A
EMC	B	Enclosure	Required protection according to the Rules shall be provided upon installation on board
Electromagnetic compatibility	Conformance with EMC Directive 2014/30/EU	Conformance with EMC directives	EN 61000-6-2 EN 61000-4-2 (ESD) Criterion B EN 61000-6-2 EN 61000-4-3 (electromagnetic fields) Criterion A EN 61000-6-2 EN 61000-4-4 (EFT burst) Criterion A EN 61000-6-2 EN 61000-4-5 (surge) Criterion A EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A EN 61000-6-2 EN 61000-6-4 (interference) Class A EN 61000-6-2 EN 61000-6-4 (conducted interference) Class A
Noise immunity	EN 61000-6-2	Noise emission	EN 61000-6-4
Basic functions	Store-and-forward switch, complies with IEEE 802.3	Status display	LEDs: US1, US2 (power supply), Fail (alarm contact), 2 LEDs per Ethernet port (Link/Activity and Speed)

Specifications may be subject to change without notice
