Product Model
FL SWITCH EP7428R-L3F1-C1
Selling Points
- 1High-speed transmission: Supports 1000/10000 Mbps (full duplex) for fast data communication.
- 2Versatile connectivity: Offers RJ45 or SFP ports for flexible network setup.
- 3Rack mount design: Includes brackets for easy installation in control panels.
- 4Conformal coating: Ensures reliability in harsh environments with a protective coating.
- 5Hot-swappable modules: Allows for quick and easy replacement of SFP modules without disrupting the network.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 486.2 mm | Height | 44.4 mm |
Depth | 446.7 mm | Note on application | Only for industrial use |
Mounting type | Rack mount, includes brackets | Connection method | RJ45 |
Note on the connection method | Auto negotiation and autocrossing | Transmission speed | 10/100/1000 Mbps |
Transmission physics | Copper | Transmission length | 100 m (per segment) |
No. of channels | RJ45 or SFP | Connection method | SFP |
Transmission speed | 1000/10,000 Mbps (full duplex) | Transmission physics | Depending on the SFP module |
Output name | Alarm relay output: 24 V DC, 1 A maximum | Product type | Switch |
Product family | Managed Switch EP7000 | Article revision | 05 |
Overvoltage category | II | Degree of pollution | 2 |
Signal contact control voltage | 24 V DC | Signal contact control current | 1 A |
MAC address table | 16k | Maximum power dissipation for nominal condition | 60 W |
Supply voltage | Based on modular power supplies used | Signal contact control voltage | 24 V DC |
Signal contact control current | 1 A | Connection name | Power supply |
Connection method | Screw connection | Conductor cross section, rigid | 0.2 mm² ... 2.5 mm² |
Conductor cross section, flexible | 0.2 mm² ... 2.5 mm² | Conductor cross section AWG | 24 ... 12 |
Degree of protection | IP20 | Ambient temperature (operation) | -40 °C ... 85 °C (Type tested to 85 °C for 16 hours) |
Ambient temperature (storage/transport) | -40 °C ... 85 °C | Permissible humidity (operation) | 5 % ... 95 % (non-condensing) |
Permissible humidity (storage/transport) | 10 % ... 95 % (non-condensing) | Vibration (operation) | in acc. with IEC 60068-2-6: 5g, 150 Hz |
Standard designation | Ambient conditions | Standards/specifications | IEC 61850-3 Ed. 2
IEEE 1613 |
Conformance | CE-compliant | Noise immunity | IEC 61850-3, IEEE 1613, EN 61000-6-2: 2005 |
Specifications may be subject to change without notice
