Product Model
FL WLAN 2101
Selling Points
- 1Dual-band connectivity for 2.4 GHz and 5 GHz frequencies.
- 2Supports IEEE 802.11 a/b/g/n wireless standard with up to 300 Mbps data throughput.
- 3Internal dual 5 dBi MIMO antennas for reliable coverage and reduced material costs.
- 4Web-based management and automated CLI for easy configuration and quality of service (QoS) support.
- 5Class I Division 2 approval for installation in hazardous rated areas, ensuring safety and reliability.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Note on application | Only for industrial use | CE note | The products are offered exclusively for export outside the EU and the European Economic Area. |
Product type | Wireless module | Type | Stand-Alone |
Article revision | 10 | Overvoltage category | none |
Pollution degree | 2 | Number | 1 |
Type | IEEE 802.11 a/b/g/n 2.4 GHz and 5 GHz to 300 Mbps | Assembly note | Permanently installed |
Maximum power dissipation for nominal condition | 4.5 W | Connection technology | COMBICON |
Connection method | Push-in spring connection | Note on the connection method | Recommended conductor cross section: 0.75 mm²
Recommended ferrule: connection length 10 mm
Recommended crimping pliers: trapezoidal or square |
Designation | 1966101 FMC 1,5/ 3-STF-3,5 | Number of positions | 3 |
Cross section range AWG | 24 ... 16 (Use copper wires rated 75° C (UL)) | Supply voltage | 24 V DC (SELV) |
Supply voltage range | 18 V DC ... 32 V DC (PELV/SELV)
9 V DC ... 32 V DC (PELV/SELV (HW version 06 or later)) | Supply current | typ. 120 mA (at 24 V DC) |
Current consumption | max. 250 mA (at 18 V DC)
max. 400 mA (at 9 V DC) | Connection method | Push-in spring connection |
Conductor cross section, rigid | 0.2 mm² ... 1.5 mm² | Conductor cross section, flexible | 0.2 mm² ... 1.5 mm² |
Conductor cross section AWG | 24 ... 16 | Stripping length | 10 mm |
Number | 2 | Connection method | permanently installed |
Note on the connection method | MIMO | Gain | 5 dBi |
Operating modes | Access Point / Client Adapter / Repeater | Configuration | Web-based management, automated CLI |
Quality of service (QoS) | Yes | Security | 802.11i
WPA PSK (preshared key)
WPA2
AES
TKIP
MAC filter
Supports 802.1X/RADIUS |
Wireless licenses | USA, Canada | Country support | USA
Canada |
Number of interfaces | 1 | Connection method | RJ45 |
Note on the connection method | Auto negotiation and autocrossing | Transmission speed | 10/100 Mbps |
Transmission physics | Copper | Transmission length | 100 m (per segment) |
No. of channels | 1 (RJ45 ports) | Designation | Wireless LAN |
Antenna connection method | (Internal) | Frequency band | 2.4 GHz
5 GHz |
Wireless standard | WLAN
IEEE 802.11
a
b
g
n
Wi-Fi 4 | Transmission power | max. 20 dBm (EIRP) |
Number of wireless interfaces | 1 IEEE 802. 11 a/b/g/n | Wireless modules that can be connected | 60 (In access point mode) |
Width | 62.8 mm | Height | 36.5 mm |
Depth | 113.2 mm | Note on dimensions | Outside dimensions |
Material base plate | Die-cast zinc, nickel-plated | Housing material | Polycarbonate, PC |
Degree of protection | IP65
IP66
IP67
IP68 | Ambient temperature (operation) | -40 °C ... 60 °C |
Note | Degree of protection when installed | Air pressure (operation) | 800 hPa ... 1080 hPa (up to 2000 m above sea level) |
Air pressure (storage/transport) | 660 hPa ... 1080 hPa (up to 3500 m above sea level) | Ambient temperature (storage/transport) | -40 °C ... 85 °C |
Permissible humidity (operation) | 5 % ... 95 % (non-condensing) | Permissible humidity (storage/transport) | 5 % ... 95 % (non-condensing) |
Standards/regulations | EN 61000-4-2 | Contact discharge | ± 4 kV |
Discharge in air | ± 8 kV | Indirect discharge | ± 6 kV |
Standards/regulations | EN 61000-4-3 | Frequency range | 80 MHz ... 1000 MHz |
Test field strength | 10 V/m | Frequency range | 1000 MHz ... 6000 MHz |
Test field strength | 3 V/m | Standards/regulations | EN 61000-4-4 |
Comments | ±2.2 kV | Standards/regulations | EN 61000-4-5 |
Signal | ± 0.5 kV (symmetrical)
± 1 kV (asymmetrical) | Standards/regulations | EN 61000-4-6 |
Frequency range | 0.15 MHz ... 80 MHz | Voltage | 10 V |
Standards/regulations | FCC/CFR 47, Part 15.107 | Test result | Class B |
Standards/regulations | FCC/CFR 47, Part 15.109 | Test result | Class A |
Standards/regulations | ICES-003 Issue 6 section 6.1 | Test result | Class B |
Standards/regulations | ICES-003 Issue 6 section 6.2 | Test result | Class A |
Mounting type | Single-hole mounting | Assembly note | Internal antenna |
Specifications may be subject to change without notice
