Product Model
FL WLAN 5101
Selling Points
- 1Up to 300 Mbps wireless throughput for bandwidth-demanding applications.
- 2Just 40 mm wide in a metal housing, ideal for confined spaces like control cabinets.
- 3Simplifies wireless network management with a single web interface for all access points.
- 4Supports both 2.4 GHz and 5 GHz bands for flexible network setup.
- 5802.11i WPA PSK and WPA2 AES TKIP for secure wireless communication.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Wireless module | Type | Stand-Alone |
Article revision | 09 | Pollution degree | 2 |
Number | 1 | Type | IEEE 802.11 a/b/g/n 2.4 GHz and 5 GHz to 300 Mbps |
Assembly note | Permanently installed | Maximum power dissipation for nominal condition | 4.8 W |
Connection method | Via COMBICON | Supply voltage | 24 V DC |
Supply voltage range | 10 V DC ... 36 V DC | Supply current | 200 mA |
Interface | Ethernet | Number | 2 |
Connection method | RJ45 jack | Number | 3 |
Operating modes | Access point/client adapter/repeater/WDS bridge | Basic functions | SNMP (V2/V3), CLI, WPS, DHCP, DCP, BootP, HTTP, HTTPS, Syslog, SD card, dual FW image, 1 x DI, 1 x DO, 2 x Ethernet 10/100 Mbit, auto crossover, auto negotiation, MODE button |
Configuration | Cluster management, web-based management, WPS | Security | 802.11i
WPA PSK (preshared key)
WPA2
AES
TKIP
Supports 802.1X/RADIUS
MAC filter |
Wireless licenses | USA, Canada | Designation | Wireless LAN |
Antenna connection method | RSMA (female) | Number | 3 |
Frequency band | 2.4 GHz
5 GHz | Wireless standard | WLAN
IEEE 802.11
a
b
g
n |
Transmission power | max. 23 dBm (EIRP) | Number of wireless interfaces | 1 IEEE 802. 11 a/b/g/n |
Width | 40 mm | Height | 109 mm |
Depth | 109 mm | Note on dimensions | Height with antenna socket, without antenna cable |
Color | silver grey | Degree of protection | IP20 |
Ambient temperature (operation) | -25 °C ... 60 °C (extended temperature range on request) | Air pressure (operation) | 800 hPa ... 1080 hPa (up to 2000 m above sea level) |
Air pressure (storage/transport) | 660 hPa ... 1080 hPa (up to 3500 m above sea level) | Ambient temperature (storage/transport) | -40 °C ... 80 °C |
Permissible humidity (operation) | 10 % ... 95 % (non-condensing) | Permissible humidity (storage/transport) | 10 % ... 95 % (non-condensing) |
Mounting type | DIN rail mounting | Assembly note | Antenna not included |
Specifications may be subject to change without notice
