Product Model
IB IL EC AR 48/10A-PAC
Selling Points
- 1Homing Position Detection: Equipped with an incremental encoder for precise homing position detection.
- 2Position, Speed, and Torque Control: Offers point-to-point positioning function with variable frequency drive.
- 3Electronic Commutation: Utilizes Hall sensors for electronic commutation.
- 4Wide Voltage Range: Compatible with supply voltage range of 12 V DC to 48 V DC ±15%.
- 5Durable Design: Built with a robust design featuring IP20 protection and suitable for DIN rail mounting.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 97.6 mm | Height | 166 mm |
Depth | 85 mm | Connection method | Inline data jumper |
Transmission speed | 500 kbps | Connection method | RS-232 |
ID code (dec.) | 195 | ID code (hex) | C3 |
Length code (hex) | 03 | Length code (dec) | 03 |
Process data channel | 48 bit | Input address area | 48 bit |
Output address area | 48 bit | Register length | 64 bit |
Required parameter data | 8 Byte | Required configuration data | 5 Byte |
Number of inputs | 3 | Connection method | MINI COMBICON |
Connection technology | 3-conductor (signal, Us, GND) | Number of positions | 3 |
Input voltage | 24 V DC | Number of inputs | 1 |
Input frequency (5 V) | max. 1 MHz | Input frequency (5 V) | max. 500 kHz (At 4 V voltage level) |
Input frequency (24 V) | max. 100 kHz (At 20 V voltage level) | Product type | I/O component |
Product family | Inline | Type | modular |
Article revision | 12 | Supply voltage | 7.5 V DC (via voltage jumper) |
Current draw | max. 120 mA
typ. 30 mA | Supply voltage | 24 V DC (via voltage jumper) |
Supply voltage range | 19.2 V DC ... 30 V DC (including all tolerances, including ripple) | Current draw | max. 150 mA
typ. 100 mA |
Supply voltage | 24 V DC (nominal value) | Connection method | 2-pos. COMBICON connector |
Designation | Power supply | Supply voltage range | 12 V DC ... 48 V DC ±15 % (Overvoltage switch-off shutdown U |
Max. current carrying capacity | 10 A | Test voltage: Logic UL / I/O / motor | 500 V AC |
Connection name | Front MSTB | Connection method | Screw connection |
Conductor cross section rigid | 0.2 mm² ... 2.5 mm² | Conductor cross section flexible | 0.2 mm² ... 2.5 mm² |
Conductor cross section AWG | 24 ... 12 | Stripping length | 8 mm |
Connection method | Screw connection | Conductor cross section, rigid | 0.2 mm² ... 2.5 mm² |
Conductor cross section, flexible | 0.2 mm² ... 2.5 mm² | Conductor cross section AWG | 24 ... 12 |
Stripping length | 8 mm | Connection method | Screw connection |
Conductor cross section, rigid | 0.14 mm² ... 2.5 mm² | Conductor cross section, flexible | 0.2 mm² ... 2.5 mm² |
Conductor cross section AWG | 28 ... 16 | Degree of protection | IP20 |
Ambient temperature (operation) | -25 °C ... 55 °C | Air pressure (operation) | 80 kPa ... 106 kPa (up to 2000 m above sea level) |
Air pressure (storage/transport) | 70 kPa ... 106 kPa (up to 3000 m above sea level) | Ambient temperature (storage/transport) | -25 °C ... 85 °C |
Permissible humidity (operation) | 75 % ... 85 % (75% permanent, 85% occasionally) | Permissible humidity (storage/transport) | 75 % ... 85 % (75% permanent, 85% occasionally) |
Protection class | III (IEC 61140, EN 61140, VDE 0140-1) | Noise emission | Noise emission test of the housing EN 55011:1991 class A in accordance with EN 61000-6-4 |
Mounting type | DIN rail mounting |
