Product Model
IB IL SCN-12
Selling Points
- 1Color-Coded Identification: Easily identify channels with color-coded markings.
- 2Commercial Grade: Designed for high-performance digital applications.
- 3Environmentally Friendly: Compliant with China RoHS, no hazardous substances above threshold values.
- 4Compact Design: Dimensions: Width 12 mm, Height 136.2 mm, Depth 41 mm.
- 5UL and cUL Recognized: Meets safety standards for electrical connections.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Plug | Conductor cross section, rigid | 0.08 mm² ... 1.5 mm² |
Conductor cross section, flexible | 0.08 mm² ... 1.5 mm² | Conductor cross section AWG | 28 ... 16 |
Stripping length | 8 mm | Width | 12 mm |
Height | 136.2 mm | Depth | 41 mm |
Specifications may be subject to change without notice
