Product Model
IB L2 BOX AO 1/2/U M12
Selling Points
- 1High-Precision Analog Output: Provides accurate analog voltage signals from -10 to +10 VDC.
- 2Compact Design: Compact M12 module for easy integration into control cabinets and distribution boxes.
- 3Reliable Connectivity: 2-conductor connection technology ensures stable and secure signal transmission.
- 4Flexible Installation: Suitable for various industrial applications, including sensors and actuators.
- 5Durable Construction: Built with robust materials for long-lasting performance in harsh environments.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Maximum power dissipation for nominal condition | 1.92 W | I/O voltage | ± 24 V DC 5 % (ripple (via INTERBUS-Loop 2)) |
I/O voltage range | 19.2 V DC ... 30 V DC | Max. current consumption | 90 mA (from INTERBUS-Loop 2) |
Typical current consumption | 80 mA (from INTERBUS-Loop 2) | Connection method | QUICKON fast connection |
Width | 62 mm | Height | 60 mm |
Length | 95 mm |
Specifications may be subject to change without notice
