Product Model

IB L2-M ESTOP-ADAP 1/1 M12

Manufacturer

Phoenix Contact

Category

Distributors for M8, M12, and AS-Interface connections

Product ID

21294

In Stock
Last updated: 2025/4/17
View Specifications
Phoenix Contact IB L2-M ESTOP-ADAP 1/1 M12

Selling Points

  • 1Reliable Emergency-Stop Solution: Designed for critical applications, this plug ensures safe shutdown with its high insulation resistance (≥ 10 GΩ) and overvoltage category II.
  • 2Versatile Connectivity: Compatible with molded and unshielded connectors using QUICKON IDC terminal block connection technology, supporting a range of 0.14 mm² to 0.34 mm².
  • 3Durable Construction: Built with TPU, hardly inflammable and self-extinguishing material, along with zinc die-cast, nickel-plated screw connections for added durability.
  • 4Industrial-Grade Performance: Operates within a wide ambient temperature range (-25 °C to 90 °C) and features IP65 and IP67 degrees of protection.
  • 5Easy Installation: With an insertion/withdrawal cycle of ≥ 100, this plug ensures long-lasting performance in demanding industrial environments.
Product Details
IB L2-M ESTOP-ADAP 1/1 M12
Phoenix Contact

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
General
with center distance of 18 mm, suitable for molded connectors and unshielded connectors that can be assembled with QUICKON IDC terminal block connection technology and a connection range of 0.14 mm² to 0.34 mm²
Product type
Y-distributor
Number of positions
5
No. of cable outlets
2
Shielded
no
Coding
A
Thread type
M12
Overvoltage category
II
Degree of pollution
3
Insulation resistance
≥ 10 GΩ
Nominal voltage U
48 V AC 60 V DC
Nominal current I
4 A
Status display
no
Status display present
No
Length
50.1 mm
Center distance
18 mm
Flammability rating according to UL 94
HB
Seal material
NBR
Material of grip body
TPU, hardly inflammable, self-extinguishing
Contact material
CuZn
Contact surface material
Ni/Au
Contact carrier material
TPU GF
Material for screw connection
Zinc die-cast, nickel-plated
Type
Socket straight M12
Coding type
A
Type
Socket straight M12
Coding type
A
Type
Plug straight M12
Coding type
A
Insertion/withdrawal cycles
≥ 100
Degree of protection
IP65 IP67
Ambient temperature (operation)
-25 °C ... 90 °C (Plug / socket)
Standard designation
M12 connector
Standards/specifications
IEC 61076-2-101

Specifications may be subject to change without notice
