Product Model
IBS RL 24 DIO 8/8/8-T
Selling Points
- 1Durable zinc die-cast housing ensures maximum availability in harsh environments.
- 2Advanced diagnostic capabilities for system reliability and efficiency.
- 3Robust against dust and water, suitable for direct installation near welding tongs.
- 4Supports 500 kbaud twisted pair or 2 Mbaud fiber optic technology for fast data transfer.
- 5QuickON fast connection method for power supply cable and simple cutting tool for fiber optic cable assembly.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 179 mm | Height | 67 mm |
Depth | 71 mm | Note on dimensions | with bus connection plugs and mounting panel |
Connection method | IP67 RL connector | Designation connection point | Copper cable |
Transmission speed | 500 kbps | Transmission physics | Copper |
Input name | Digital inputs | Number of inputs | 8 |
Connection technology | 2-, 3-, 4-conductor | Input voltage range "0" signal | 0 V DC ... 5 V DC |
Input voltage range "1" signal | 11 V DC ... 30 V DC | Typical input current per channel | 3 mA |
Delay at signal change from 0 to 1 | 3 ms | Delay at signal change from 1 to 0 | 3 ms |
Protective circuit | Electronic short-circuit/overload protection for each group | Output name | Digital outputs |
Connection technology | 2-, 3-conductor | Number of outputs | 8 |
Protective circuit | Electronic short-circuit/overload protection for each channel | Output voltage | 24 V DC |
Maximum output current per group | 2 A | Maximum output current per channel | 500 mA |
Nominal output voltage | 24 V | Output voltage when switched off | max. 1 V |
Output current when switched off | max. 100 µA | Nominal load, inductive | 12 VA (1.2 H, 48 Ω) |
Nominal load, lamp | 12 W | Nominal load, ohmic | 12 W |
Maximum operating frequency with ohmic nominal load | max. 300 Hz | Behavior with overload | Auto restart |
Behavior with inductive overload | Output can be destroyed | Overcurrent shut-down | min. 0.7 A |
Output current with ground connection interrupt when switched off | max. 25 mA | Product type | I/O component |
Product family | Ruggedline | Type | Block design |
No. of channels | 16 | Supply voltage | 24 V DC |
Supply voltage range | 18.5 V DC ... 32 V DC (including ripple) | Supply current | typ. 120 mA (plus sensor current) |
Ripple | Max 3.6 V | Test voltage: Between bus logic and I/O | 500 V AC, 50 Hz, 1 min |
Test voltage: Between bus logic and outputs | 500 V AC, 50 Hz, 1 min | Connection method | M12 connector |
Ambient temperature (operation) | 0 °C ... 55 °C | Degree of protection | IP65/IP67 |
Note | Seal unused slots/connections to ensure the degree of protection. | Air pressure (operation) | 860 hPa ... 1080 hPa (up to 1500 m above sea level) |
Air pressure (storage/transport) | 660 hPa ... 1080 hPa (up to 3500 m above sea level) | Ambient temperature (storage/transport) | -25 °C ... 70 °C |
Permissible humidity (operation) | 100 % | Permissible humidity (storage/transport) | 95 % (non-condensing) |
Mounting type | Wall mounting |
Specifications may be subject to change without notice
