Product Model
PLC-RSC-120UC/1/SEN/SO46
Selling Points
- 1Time savings of up to 60%.
- 2No need for additional modular terminal blocks.
- 3Efficient connection to system cabling using V8 adapter.
- 4Safe isolation according to DIN EN 50178 between coil and contact.
- 5Space savings of up to 80%.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
CE note | The products are offered exclusively for export outside the EU and the European Economic Area. | Product type | Relay Module |
Application | Input function | Operating mode | 100% operating factor |
Mechanical service life | 2x 10 | Date of last data management | 14.05.2024 |
Overvoltage category | III | Pollution degree | 3 |
Nominal input voltage U | 120 V AC
110 V DC | Typical input current at U | 3.5 mA |
Typical response time | 6 ms | Typical release time | 15 ms |
Protective circuit | Bridge rectifier | Operating voltage display | Yellow LED |
Contact switching type | 1 N/O contact | Type of switch contact | Single contact |
Contact material | AgSnO | Maximum switching voltage | 250 V AC/DC |
Limiting continuous current | 6 A | Connection method | Screw connection |
Stripping length | 8 mm | Screw thread | M3 |
Conductor cross section rigid | 0.14 mm² ... 2.5 mm² | Conductor cross section flexible | 0.14 mm² ... 2.5 mm²
0.2 mm² ... 2.5 mm² (Single ferrule)
2x 0.5 mm² ... 1.5 mm² (TWIN ferrule) |
Conductor cross section AWG | 26 ... 14 | Tightening torque | 0.6 Nm ... 0.8 Nm |
Width | 6.2 mm | Height | 80 mm |
Depth | 94 mm | Flammability rating according to UL 94 | V0 (Housing) |
Ambient temperature (operation) | -40 °C ... 60 °C | Ambient temperature (storage/transport) | -40 °C ... 85 °C |
Standards/regulations | IEC 60664
EN 50178 | Assembly note | in rows with zero spacing |
Specifications may be subject to change without notice
