Product Model
RAD-CAB-PFP400-100
Selling Points
- 1Solid inner conductor ensures reliable signal transmission.
- 24.1 / 6.9 / 10.4 dB attenuation at 0.9 / 2.4 / 5.8 GHz frequencies.
- 3Outside diameter of 10 mm (0.4 in.) for robust connectivity.
- 42x N male connections for easy integration.
- 5Widely available through global suppliers like X-On Electronics.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Coaxial cable | Frequency range | 400 MHz ... 5.8 GHz |
Impedance | 50 Ω | Connection method | N (male) |
Notes | Both sides | Connection method | N (male) |
Outer sheath, material | PE | Cable length | 30 m |
Cable type | PFP-400 | External cable diameter | 10.00 mm |
Outer sheath, material | PE | External sheath, color | black |
Bending radius, long-term | 25.00 mm | 868 / 900 MHz | 4.1 dB |
2.4 GHz | 6.9 dB | Ambient temperature (operation) | -40 °C ... 85 °C |
Ambient temperature (storage/transport) | -40 °C ... 70 °C |
Specifications may be subject to change without notice
