Product Model
RAD-IN-4A-I
Selling Points
- 1Designed for easy installation on DIN rail systems.
- 2Compatible with 9V DC supply voltage range.
- 3Built with high-quality components for reliable performance.
- 4Secure and easy-to-use screw connection method.
- 5Covered by a 3-year warranty for peace of mind.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Extension module | Maximum power dissipation for nominal condition | 3.12 W |
Connection method | Screw connection | Supply voltage range | 9 V DC ... 30 V DC (via bus foot) |
Typical current consumption | 100 mA | Max. current consumption | 130 mA |
Description of the input | Current input | Number of inputs | 4 |
Current input signal | 4 mA ... 20 mA | Input resistance current input | < 170 Ω |
Resolution | 16 bit | Connection method | Screw connection |
Stripping length | 8 mm | Conductor cross section flexible | 0.2 mm² ... 2.5 mm² |
Conductor cross section rigid | 0.2 mm² ... 4 mm² | Cross section AWG | 24 ... 14 |
Screw thread | M3 | Width | 22.5 mm |
Height | 99 mm | Depth | 114.5 mm |
Color (Housing) | green (RAL 6021) | Material (Housing) | Polyamide |
Degree of protection | IP20 | Ambient temperature (operation) | -20 °C ... 65 °C
-4 °F ... 149 °F |
Ambient temperature (storage/transport) | -40 °C ... 85 °C | Certificate | CE-compliant |
Identification | Class I, Div. 2, Groups A, B, C, D | Assembly note | on standard DIN rail NS 35 in accordance with EN 60715 |
Mounting position | any |
Specifications may be subject to change without notice
