Product Model
RAD-ISM-900-DATA-BD
Selling Points
- 1All-in-One Solution: Combines Master, Slave, and Store-and-Forward Repeater/Slave functions.
- 2Flexible Interfaces: Supports RS-232, RS-485, and RS-422 protocols for versatile connectivity.
- 3Remote Diagnostics: Enables remote diagnostics via second port on radios and terminal windows in the GUI.
- 4Hazardous Area Approval: Class I, Div. 2 approved for use in hazardous areas (UL, CUL, and CSA certified).
- 5High-Performance Transmission: 1 watt transmit power with up to 30 dBm transmit capacity and -110 dBm receiver sensitivity.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Wireless module | Supply voltage | 24 V DC |
Supply voltage range | 9 V DC ... 30 V DC | Typical current consumption | 110 mA |
Max. current consumption | 180 mA | Connection method | Screw connection |
Stripping length | 8 mm | Conductor cross section flexible | 0.2 mm² ... 2.5 mm² |
Conductor cross section rigid | 0.2 mm² ... 4 mm² | Cross section AWG | 24 ... 12 |
Screw thread | M3 | Data rate | 1,2 / 2,4 / 9,6 / 19,2 / 38,4 kBit/s |
Connection method | D-SUB-9 female connector | File format/coding | Asynchronous |
Data flow control/protocols | RTS/CTS | Data rate | 1,2 / 2,4 / 9,6 / 19,2 / 38,4 kBit/s |
Connection method | COMBICON plug-in screw terminal block | Direction | Bi-directional |
Frequency | 900 MHz | Frequency range | 902 MHz ... 928 MHz |
Number of channel groups | 4 | Number of channels per group | 63 |
Transmission power | 1 W | Frequency band | 900 MHz |
Width | 22.5 mm | Height | 99 mm |
Depth | 114.5 mm | Color | green |
Housing material | Polyamide PA non-reinforced | Degree of protection | IP20 |
Ambient temperature (operation) | -40 °C ... 70 °C
-40 °F ... 158 °F | Ambient temperature (storage/transport) | -40 °C ... 85 °C |
Conformance | FCC Directive, Part 15.247
ISC Directive RSS 210 | UL, USA / Canada | Class I, Div. 2, Groups A, B, C, D |
Electromagnetic compatibility | FCC Part 15.247 / ISC RSS 210 | Assembly note | on standard DIN rail NS 35 in accordance with EN 60715 |
Mounting position | any |
Specifications may be subject to change without notice
