Product Model
UMK 22-REL 24/21-ST (BASE)
Selling Points
- 1Ensures secure separation between coil and contact sides.
- 2Conveniently mounts on DIN rails for easy installation.
- 3Supports solid and flexible conductors with screw connections.
- 4Meets REACh SVHC and China RoHS standards for environmental safety.
- 5Designed for a 50-year use period with environmentally friendly materials.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Relay socket | Application | Universal |
Operating mode | 100% operating factor | Nominal voltage U | 250 V AC/DC |
Nominal current I | 10 A | Connection method | Screw connection |
Stripping length | 6 mm | Screw thread | M3 |
Conductor cross section rigid | 0.14 mm² ... 2.5 mm² | Conductor cross section flexible | 0.14 mm² ... 1.5 mm² |
Conductor cross section AWG | 30 ... 14 | Connection method | Screw connection |
Stripping length | 6 mm | Screw thread | M3 |
Conductor cross section rigid | 0.14 mm² ... 2.5 mm² | Conductor cross section flexible | 0.14 mm² ... 1.5 mm² |
Conductor cross section AWG | 30 ... 14 | Width | 22.5 mm |
Height | 77 mm | Depth Retaining bracket | 50 mm (with retaining bracket) |
Ambient temperature (operation) | -20 °C ... 65 °C | Ambient temperature (storage/transport) | -40 °C ... 85 °C |
Mounting type | DIN rail mounting | Assembly note | in rows with zero spacing |
Mounting position | any |
Specifications may be subject to change without notice
