Product Model
UMK- 8 OM-R/PF/MKDS/P
Selling Points
- 1High-Performance Interface Module: The UMK- 8 OM-R/PF/MKDS/P is designed for high-performance applications with 8 solid-state relays.
- 2Enhanced Security Features: Equipped with a security latch and integrated fuse for line protection.
- 3Flexible Connectivity Options: Offers screw connection and plug-in socket for easy integration.
- 4Real-Time Status Indication: Includes a light indicator for real-time status monitoring of each channel.
- 5Versatile Compatibility: Compatible with digital I/O modules and various control logic configurations.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Solid-state relay module | No. of channels | 8 |
Compatible components | Digital I/O modules | With components | no |
Input voltage range | 4 V ... 32 V | Typical input current at U | 30 mA (Optocoupler dependent) |
Operating voltage display | Yellow LED | Status display/channel | Yellow LED |
Compatible components | Digital I/O modules | Limiting continuous current | 5 A (Optocoupler dependent) |
Nominal supply voltage | 125 V | Error detection (line break / short-circuit) | no |
Connection method | Screw connection | Stripping length | 8 mm |
Screw thread | M3 | Number of connections | 2 |
Number of positions | 12 | Conductor cross section rigid | 0.2 mm² ... 4 mm² |
Conductor cross section flexible | 0.2 mm² ... 2.5 mm² | Conductor cross section AWG | 24 ... 12 |
Connection method | Screw connection | Stripping length | 8 mm |
Screw thread | M3 | Number of connections | 16 |
Number of positions | 3 | Conductor cross section rigid | 0.2 mm² ... 6 mm² |
Conductor cross section flexible | 0.2 mm² ... 4 mm² | Conductor cross section AWG | 24 ... 10 |
Status display present | Yes | Width | 180 mm |
Height | 77 mm | Depth | 72 mm |
Color | green (RAL 6021) | Housing insulation material | PVC, side panel PA non-reinforced, |
Ambient temperature (operation) | -20 °C ... 50 °C | Ambient temperature (storage/transport) | -20 °C ... 70 °C |
Standards/regulations | DIN VDE 0110b, Gr. C for 250 V DC
DIN VDE 0160 (in relevant parts) | Assembly note | in rows with zero spacing |
Mounting position | any |
Specifications may be subject to change without notice
