Product Model
UMK-HD62SUB/M/PTDA GNGY
Selling Points
- 1High-quality insulation with air clearances and creepage distances.
- 2Competitive pricing for wholesale electronic components.
- 3100% brand new and original products available in stock.
- 4Suitable for various industrial automation applications.
- 5Reliable overvoltage protection for secure operations.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Interface module | Product family | VARIOFACE |
Overvoltage category | I | Pollution degree | 2 |
Nominal voltage U | 24 V DC | Max. current carrying capacity per branch | 1 A |
Rated insulation voltage | 50 V | Rated surge voltage | 0.4 kV (Basic insulation) |
Connection method | Spring-cage connection with direct connector-in method | Number of positions | 63 |
Conductor cross section rigid | 0.2 mm² ... 1.5 mm² | Conductor cross section flexible | 0.2 mm² ... 1.5 mm² |
Conductor cross section AWG | 24 ... 16 | Connection method | D-SUB pin strip |
Number of positions | 62 | Note | High Density |
Status display present | No | Width | 79 mm |
Height | 77 mm | Depth | 50 mm |
Ambient temperature (operation) | -20 °C ... 50 °C | Standards/regulations | DIN EN 50178 |
Mounting type | DIN rail mounting | Mounting position | any |
Notes on operation | For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. |
Specifications may be subject to change without notice
