Product Model
UMK-SE 11,25-1 BK
Selling Points
- 1Versatile Design: Adaptable for various electronic modules, enhancing flexibility in electronic installations.
- 2Durable Material: Crafted from green polyamide (RAL 6021), ensuring high flammability rating (UL 94 V2) and environmental compliance.
- 3Easy Assembly: Engineered for ease of assembly and disassembly, catering to professionals and DIY enthusiasts.
- 4Compliant Standards: Meets EU RoHS and China RoHS requirements, ensuring safe and compliant use.
- 5Compact Dimensions: Measures 11.25 mm in length, 77 mm in external profile width, and 72.2 mm in internal profile width.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Panel mounting base side part | Housing type | Press-drawn section housings |
Housing series | UMK | Product family | UMK SE |
Type | Lateral element | Ventilation openings present | no |
Length | 11.25 mm | Profile width (external) | 77 mm |
Profile width (internal) | 72.2 mm | Color (Housing) | black (RAL 9005) |
Flammability rating according to UL 94 | V2 | Housing material | Polyamide |
Surface characteristics | untreated | Ambient temperature (operation) | -40 °C ... 105 °C (depending on power dissipation) |
Specifications may be subject to change without notice
