Product Model
UMKS- F48F-VR
Selling Points
- 148-Position VARIOFACE Module: Designed for IEC 603/DIN 41612 connectors, type F, with 48 positions.
- 2Functional Insulation: Ensures reliable electrical performance with functional insulation.
- 3Screw Connection: Easy to install with screw connection method.
- 4Operational Temperature Range: Suitable for ambient temperatures between -20 °C and 50 °C.
- 5Durable Construction: Made from high-quality polyamide PA non-reinforced housing material.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Interface module | Product family | VARIOFACE |
Number of positions | 48 | Nominal voltage U | 250 V AC |
Max. current carrying capacity per branch | 2 A | Connection in acc. with standard | IEC / EN |
Connection method | Screw connection | Stripping length | 8 mm |
Screw thread | M3 | Conductor cross section rigid | 0.2 mm² ... 4 mm² |
Conductor cross section flexible | 0.2 mm² ... 2.5 mm² | Conductor cross section AWG | 24 ... 12 |
Connection method | IEC 603/DIN 41612 connection | Number of connections | 1 |
Number of positions | 48 | Status display present | No |
Width | 123.8 mm | Height | 77 mm |
Depth | 72 mm | Color | green (RAL 6021) |
Housing insulation material | Polyamide PA non-reinforced | Ambient temperature (operation) | -20 °C ... 50 °C |
Ambient temperature (storage/transport) | -20 °C ... 70 °C | Standards/regulations | DIN VDE 0110 |
Mounting position | any | Notes on operation | For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. |
Specifications may be subject to change without notice
