Product Model
150-SD3NBD
Selling Points
- 11. High Performance Capability: The Allen Bradley 150-SD3NBD SMC-50 motor controller delivers exceptional performance with a 520A line rating, making it suitable for demanding industrial applications.;
- 22. Versatile Control Voltage: Compatible with 100-240V AC, this controller provides flexibility in various industrial settings, ensuring reliable operation across different voltage conditions.;
- 33. Advanced Protection Mechanisms: Equipped with an RC snubber network and Type 1 SCPD, the controller offers robust protection against short circuits and other electrical hazards, ensuring safe and reliable operation.;
- 44. Configurable Options: Although the config tool is not provided, the controller can be configured using optional tools like the 150-SM6 or Human Interface Module (HIM), or software such as Drive Exec, providing flexibility in customization.;
- 55. Industrial-Grade Design: Designed with an open enclosure, this motor controller is built to withstand the rigors of industrial environments, ensuring long-term performance and minimal downtime.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Dimension Unit | CM | Weight Unit | KG |
Weight | 75.387 | Stock Status | NON_STOCKED |
Dimension Length | 40.64 | Dimension Width | 41.91 |
Lead Time | 20 | Dimension Height | 33.02 |
Quick Turnaround | false | Preferred Availability | false |
Repairable | REPAIRABLE | Power poles | Heatsink hockey puck thyristor modular design |
Control modules | Thermoset and thermoplastic moldings | Metal parts | Plated brass, copper or steel |
Enclosure | Open type | Vertical clearance, min | 15 cm |
Horizontal clearance, min | 0 cm | Number of poles | 3 |
Operating ambient temperature | 40 to 65 °C (104 to 149 °F) (refer to thermal wizard) | Atmospheric protection | ANSI/ISA - 71.04-2013, class G3 environment |
Mounting orientation | Vertical | Pollution degree | 2 |
Altitude | 2000 m (6560 ft) without derating, for ops above 2000...7000 m (6560...22965 ft) maximum, refer to Thermal Wizard | EMC immunity levels | Surge transient per EN 60947-4-2 |
EMC emission levels | Radiated emissions: Class A (per EN 60947-4-2) | Protection against electrical shock | IP00 (IP20 - control terminals only) per IEC |
Humidity | 5...95% (noncondensing) | Rated surrounding temperature range without derating | -20 °C |
Storage and transportation temperature | -25 °C | Control terminals | ClAing yoke connection, M3 screw clA |
Power terminal markings | NEMA, CENELEC EN50 012 | Function | Single direction |
Vibration | Opsal: 1.0 G peak, 0.15 mm (0.006 in) displacement | Power terminal lugs | Two 13.5 mm (0.53 in) diam holes per power pole |
Height | 1295.4 mm | Depth | 355.6 mm |
Width | 914.4 mm | Shock | Opsal: 15 G |
Degree of protection (IP) | IP00 | Output current, max | 300mA @ 24V DC supply (terminals 8 and 12) for control power |
Overload type | Electronic - using I2t algorithm | Control module battery type | CR 2032 for control power |
Control power ride through | 22 ms for control power | Short circuit protection device performance (SCPD) type | Type 1 |
Integrated motor overload protection | Yes | Optional controller feature | Param configuration/progming tools |
Standard available fault current, max | 42kA @ 600V, typical current 2500 A non-time delay fuse for inside delta connected motors | Standard controller feature | Torque control |
Option power adder | 5VA @ 100...240V AC, 150-SM6 (for each option installed, add to base power to obtain total power requirement) | Utilization category | MG 1 per UL/CSA/NEMA for normal duty |
High capacity available fault current, max | 65kA @ 600V, typical current 1200 A time delay Class J or Class L fuse for inside delta connected motors | Delta connected motor power | Normal/standard duty: 250...700Hp @ 460V AC, 60 Hz, 3-phase |
Line connected motor power | Normal/standard duty: 75...200Hp @ 230V AC, 60 Hz, 3-phase | Insulation voltage | Rated 500V per IEC for power circuit |
Transient protection | Metal oxide varistors: 220 J | Delta connected motor current | Normal/standard duty: 302...900A @ 400/415/460V AC, 3-phase |
Line connected motor current | Normal/standard duty: 174...520A @ 400/415/460V AC, 3-phase | Dielectric withstand | 2500V per IEC for power circuit |
Rated impulse voltage | 6000V per IEC for power circuit | Operating frequency | 47...63 Hz or DC for control power |
Repetitive peak inverse voltage rating | 1400V per UL/CSA/NEMA for power circuit | DV/DT protection | RC snubber network |
Base power draw from control module with heat sink fan | 300VA @ 100...240V AC | Trip current rating | 118% of motor FLC |
Trip classes | 5...30 | Controller type | SMC-50 |
Overload current for delta connected devices | 302 A | Overload current for line connected devices | 174 A |
Continuous duty power structure heat dissipation | 1560 W | Controller rating | 520 A |
Rated control supply voltage at AC 60 Hz | 100 | Rated control supply voltage at AC 50 Hz | 100 |
Rated operating voltage Ue | 200 | Voltage type for actuating | AC |
With display | No | NOTE | Config tool not provided,must be ord as Option(150-SM6)or Human Interf Mod(HIM)or Config Software such as Drive Exec |
Controller Ratings | D3 | Control Voltage | 100...240V AC |
Specifications may be subject to change without notice
