Rockwell Automation 1606-XLERED20Y Redundancy Module for Reliable Power Supply

Selling Points

11. Automated Load Sharing: The 1606-XLERED20Y ensures seamless operation by automatically sharing loads between connected power supplies, preventing any single point of failure.;
22. Anomaly Monitoring: This module includes advanced monitoring capabilities to detect anomalies in the redundancy circuit, ensuring that any potential issues are quickly identified and addressed.;
33. High Peak Load Capability: With a peak load capability of 32.5 A, the 1606-XLERED20Y can handle high current demands, making it suitable for demanding industrial applications.;
44. Reverse Input Polarity Protection: The module is equipped with reverse input polarity protection, safeguarding against potential electrical hazards and ensuring safe operation.;
55. Wide Operating Temperature Range: The 1606-XLERED20Y operates effectively within a wide temperature range of -40°C to +70°C, making it suitable for use in various environmental conditions.

Detailed engineering parameters based on manufacturer documentation

Parameter	Value	Parameter	Value
Dimension Unit	CM	Weight Unit	KG
Stock Status	NON_STOCKED	Dimension Length	15.081
Dimension Width	14.129	Lead Time	56
Dimension Height	6.033	Quick Turnaround	false
Preferred Availability	false	Repairable	NOT_REPAIRABLE
Operating temperature	-40 Â°C	Current, nom	10 A per Input
Connection terminals	Screw	Output	20 A
Type of accessory/spare part	Redundancy module	Accessory	Yes
Spare part	No	Power losses	1.7 W @ no load, 2.6...4.7 W @ nominal load
Output current	20 A nominal, 26 A maximum @ short circuit	MTBF	2 Mio. h (+40 Â°C, SN29500)
Lifetime, min	182 kh (+40 Â°C)	Input voltage range	18...35V DC
Voltage drop/output	100 to 500 mV	Derating	Not required
Voltage, nom	24...28V DC	Input	2 x 10 A
Decoupling	MOSFET	Depth	117 mm
Height	124 mm	Width	32 mm
Weight	0.408

Specifications may be subject to change without notice
