Product Model
1606-XLP30B
Selling Points
- 11. Compact Design: The 1606-XLP30B is designed to be compact, making it perfect for space-saving applications in industrial automation.;
- 22. Reliable Performance: With a high Mean Time Between Failures (MTBF) of 650,000 hours at 40°C, this power supply ensures reliable performance in harsh industrial environments.;
- 33. Global Input Voltage: The power supply accepts a wide range of AC and DC voltages, including 120/240V AC and 85-375V DC, making it suitable for global use.;
- 44. Safety Standards: The 1606-XLP30B meets all global safety standards, ensuring it is safe for use in various industrial settings.;
- 55. Efficient Operation: With an efficiency of 84%, this power supply reduces energy consumption and costs, making it a cost-effective solution for industrial automation needs.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Dimension Unit | CM | Weight Unit | KG |
Stock Status | STOCKED | Dimension Length | 15.189 |
Dimension Width | 14.199 | Lead Time | 5 |
Dimension Height | 6.299 | Quick Turnaround | false |
Preferred Availability | true | Repairable | NOT_REPAIRABLE |
Weight | 0.315 | Relative humidity | 5 to 95 % |
Storage temperature | -40 °C | Operating temperature | -10 °C |
Ripple and noise, max | 50 mV | Stabilized | Yes |
Rail mounting possible | Yes | Output voltage stabilized | Yes |
Special feature | - | Rated input current | <0.6A @ 100V AC |
Special family function | No power boost | Input voltage | 100â¦240V AC |
Hold-up time | >18 ms @ 100V AC | Sub group | Compact family |
Phases | 1-phase | Rated output current | 3A @ 10V |
Operational range | 85...264V AC | Adjustment range | 10 V |
Efficiency, typ | 84 % | Rated supply voltage at DC | 85 V |
Voltage type of supply voltage | AC/DC | Power output | 30 W |
Secondary voltage adjustable | Yes | Vibration | 2 g |
Degree of protection (NEMA) | Other | Wall mounting possible | Yes |
MTBF | 650000 hr @ 40 °C, SN 29500 | Special functions | No special function |
Shock | 30 G, 6 ms 20G, 11 ms | Type of electric connection | Spring clA connection |
Degree of protection (IP) | IP20 | Width | 45 mm |
Direct mounting possible | No | Depth | 91 mm |
Height | 75 mm | Product Family | Power Supply XLP |
Specifications may be subject to change without notice
