Product Model
1756-PLS
Selling Points
- 11. Reliable Power Supply: The Allen Bradley 1756-PLS power supply is engineered to provide consistent and reliable power to your ControlLogix system, minimizing downtime and ensuring continuous operation.;
- 22. Efficient Operation: Designed for optimal performance, the 1756-PLS power supply ensures efficient energy usage, reducing overall system costs and enhancing productivity.;
- 33. Compatibility with Various Chassis: Compatible with multiple Allen Bradley chassis models (Series A, B, and C), the 1756-PLS power supply offers flexibility in system integration, making it a versatile choice for various industrial automation applications.;
- 44. Robust Environmental Specifications: Operating within a temperature range of 0°C to +60°C (32°F to 140°F), the 1756-PLS power supply withstands harsh industrial environments, ensuring reliable operation under demanding conditions.;
- 55. High-Quality Build and Safety Features: Built with reinforced insulation and tested for isolation voltage up to 250V DC, the 1756-PLS power supply prioritizes safety and durability, providing peace of mind in critical industrial applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Dimension Unit | CM | Weight Unit | KG |
Weight | 0.93 | Stock Status | NON_STOCKED |
Dimension Length | 19.51 | Dimension Width | 20.4 |
Lead Time | 5 | Dimension Height | 11.81 |
Quick Turnaround | false | Preferred Availability | false |
Repairable | REPAIRABLE | Enclosure type | None (open-style) |
Surge current per point | 2 A for 10 ms every 1 s @ 60 °C (140 °F) | Current limit | <4 A |
IEC temperature code | T4 | Vibration | 2 G @ 10...500 Hz |
Shock | Operating: 30 G, Non operating: 50 G | RTB keying | User-defined mechanical |
Off-state voltage, max | 5V DC | Off-state current, max | 1.5 mA |
Nonoperating temperature | -40 °C | Radiated RF immunity | 10 V/m with 1 kHz sine-wave 80% AM from 80...2000 MHz, 10 V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz, 10 V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz, 3 V/m with 1 kHz sine-wave 80% AM from 2000...2700 MHz |
Operating temperature | 0 to 60 °C | Conducted RF immunity | 10V rms with 1 kHz sine wave 80% AM from 150 kHz...80 MHz on shielded signal ports |
Relative humidity | 5...95% noncondensing | ESD immunity | 6 kV contact discharges, 8 kV air discharges |
Emissions | IEC 61000-6-4 | North American temperature code | T4 |
Surrounding air temperature, max | 60 °C | Short-circuit protection, outputs available | No |
Redundancy | No | Wire category | 2 on signal ports, 1 on power ports |
Type of electric connection | Screw connection | Voltage type of supply voltage | DC |
Digital outputs configurable | No | Digital inputs configurable | Yes |
Suitable for safety functions | No |
Specifications may be subject to change without notice
