Schneider Electric 140AII33000 Intrinsically Safe Temperature Input Module

schneider 140AII33000

Selling Points

1Ensures safe operation in hazardous environments.
2Provides precise temperature input for reliable automation.
3Seamlessly integrates with Modicon Quantum systems.
4Built to withstand harsh industrial conditions.
5Backed by a comprehensive 2-year warranty from Schneider Electric.

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

Parameter	Value	Parameter	Value
Range of Product	Modicon Quantum automation platform	Product or Component Type	Intrinsically safe temperature input module
Software designation	Concept V2.2 and above<br />Unity Pro	Type of filter	Plus notch input filter 50/60 Hz thermocouple<br />Single low pass input filter 20 Hz thermocouple
Product destination	In conjunction with products for zone 20, 21 or 22	Analogue input number	8
Analogue input type	Low level voltage -100...100 mV<br />Low level voltage -25...25 mV<br />Thermocouple - 210...760 °C thermocouple J<br />Thermocouple - 270...1000 °C thermocouple E<br />Thermocouple - 270...1370 °C thermocouple K<br />Thermocouple - 270...400 °C thermocouple T<br />Thermocouple - 50...1665 °C thermocouple R<br />Thermocouple - 50...1665 °C thermocouple S<br />Temperature probe - 200...850 °C Pt 100, Pt 200, Pt 500, Pt 1000<br />Temperature probe - 60...180 °C Ni 100, Ni 200, Ni 500, Ni 1000<br />Thermocouple - 130...1820 ° C thermocouple B	Measurement current	0.5 mA Pt 500, Pt 1000, Ni 500, Ni 1000<br />2.5 mA Pt 100, Pt 200, Ni 100, Ni 200
Source resistance	< 200 Ohm thermocouple	Input impedance	> 10 MOhm RTD<br /> thermocouple
Common mode rejection	> 100 dB 50/60 Hz RTD<br />> 120 dB 50/60 Hz thermocouple	Cold junction compensation	Internal 32.0000000000…140.0000000000 °F (0…60 °C) thermocouple
Linearity	0.003 % of full scale RTD	Resolution	0.76 µV (16 bits) -25...25 mV millivolt<br />3.05 µV (16 bits) -100...100 mV millivolt<br />1 °C, 0.1 °C, 1 °F, 0.1 °F thermocouple<br />12 bits + sign (0.1 °C) RTD
Measurement accuracy	+/- 2 °C + 0.1 % of reading thermocouple E<br />+/- 2 °C + 0.1 % of reading thermocouple J<br />+/- 2 °C + 0.1 % of reading thermocouple K<br />+/- 2 °C + 0.1 % of reading thermocouple T<br />+/- 4 °C + 0.1 % of reading thermocouple B<br />+/- 4 °C + 0.1 % of reading thermocouple R<br />+/- 4 °C + 0.1 % of reading thermocouple S<br />+/- 0.5 °C RTD 77.0000000000 °F (25 °C)<br />+/- 0.9 °C RTD 32.0000000000…140.0000000000 °F (0…60 °C)<br />20 µV + 0.1 % of reading millivolt 77.0000000000 °F (25 °C)	Absolute accuracy error	+/- 0.05 % of full scale RTD 77.0000000000 °F (25 °C)<br />+/- 0.1 % of full scale maximum RTD 77.0000000000 °F (25 °C)
Accuracy drift according to temperature	0.15 mV/°C + 0.0015 % of reading/°C max thermocouple	Update time	1 s TC/millivolt thermocouple<br />1.35 s 3 wires RTD<br />750 ms 2 or 4 wires RTD
Isolation between channels and bus	1780 V 47...63 Hz AC for 1 minute<br />2500 V DC for 1 minute	Fault type	Broken wire<br />Out of range
Power dissipation in W	2 W	Hot swapping fallback	Not allowed per intrinsic safety standards
Protection Type	Internal fuse	marking	CE<br />II1 G/D-EEx ia IIC
Bus current requirement	400 mA	Module format	Standard
Net Weight	0.7 lb(US) (0.3 kg)	Standards	EN 50281-1-1<br />EN 50014<br />EN 50284<br />CSA C22.2 No 142<br />EN 50020<br />Directive ATEX 94/9/EC<br />EN 50039
Dust zone	Outside zone	Product Certifications	hazardous location class 1, division 1 groups A, B, C<br />C-Tick.1<br />FM Class 1 Division 2<br />SIRA 02ATEX2345X
Resistance to electrostatic discharge	4 kV contact IEC 801-2<br />8 kV on air IEC 801-2	Resistance to electromagnetic fields	9.1 V/m (10 V/m) 80…2000 Hz IEC 801-3
Ambient Air Temperature for Operation	32…140 °F (0…60 °C)	Ambient Air Temperature for Storage	-40…185 °F (-40…85 °C)
Relative Humidity	95 % without condensation	Operating altitude	<= 16404.2 ft (5000 m)
