Schneider Electric 140CPS42400 Power Supply Module

Selling Points

1Operates with a flexible input voltage range of 48 to 60 V DC, suitable for various industrial power systems.
2Delivers a maximum output current of 8 A in redundant mode, ensuring continuous operation in case one power supply fails.
3Equipped with internal overvoltage and overload protection, safeguarding the power supply and connected devices from power surges or current overloads.
4Includes an alarm output feature that triggers in the event of a power supply fault, providing a normally closed (NC) contact rated at 6 A and 220 V.
5Features a green LED labeled "PWR OK" for local signaling and comes with a 2-year warranty from MRO Electric and Supply.

Detailed engineering parameters based on manufacturer documentation

Parameter	Value	Parameter	Value
Range of Product	Modicon Quantum automation platform	Product or Component Type	Power supply module
power supply type	Redundant	Input voltage	48...60 V 48...60 V) DC
Input current	3800 mA	Inrush current	14 A 40 V
Maximum input power interruption	13 ms 48 V	Associated fuse rating	2 A, time-lag
Output voltage	5.1 V DC	Power supply output current	8 A redundant
Output overvoltage protection	Internal	Output overload protection	Internal
Power dissipation	17.2 W	Alarm output	1 NC 6 A 220 V power supply fault
Local signalling	for power (PWR OK) 1 LED (green)	marking	CE
Module format	Standard	Net Weight	1.43 lb(US) (0.65 kg)
Standards	CSA C22.2 No 142<br />UL 508	Product Certifications	cUL
Resistance to electrostatic discharge	4 kV contact IEC 801-2<br />8 kV on air IEC 801-2	Resistance to electromagnetic fields	9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3
Ambient Air Temperature for Operation	32…140 °F (0…60 °C)	Ambient Air Temperature for Storage	-40…185 °F (-40…85 °C)
Relative Humidity	95 % without condensation	Operating altitude	<= 16404.2 ft (5000 m)

Specifications may be subject to change without notice
