Product Model
140CPS42400C
Selling Points
- 1Redundant Power Supply: Ensures uninterrupted system operation with two redundant power supplies.
- 2Wide Input Voltage Range: Compatible with 48-60V DC input voltage.
- 3High Output Current: Provides 8A of output current for reliable power distribution.
- 4Internal Overvoltage Protection: Safeguards against overvoltage conditions to prevent damage.
- 5Standard Module Format: Easy integration into Modicon Quantum systems with a standard module format.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon Quantum automation platform | Product or Component Type | Power supply module |
power supply type | Redundant | Input voltage | 48...60 V 48...60 V) DC |
Input current | 3800 mA | Inrush current | 14 A 40 V |
Maximum input power interruption | 13 ms 48 V | Associated fuse rating | 2 A, time-lag |
Output voltage | 5.1 V DC | Power supply output current | 8 A redundant |
Output overvoltage protection | Internal | Output overload protection | Internal |
Power dissipation | 17.2 W | Alarm output | 1 NC 6 A 220 V power supply fault |
Local signalling | for power (PWR OK) 1 LED (green) | marking | CE |
Module format | Standard | Net Weight | 1.43 lb(US) (0.65 kg) |
Protective treatment | Conformal coating Humiseal 1A33 | Standards | UL 508<br />CSA C22.2 No 142 |
Product Certifications | cUL | Resistance to electrostatic discharge | 4 kV contact IEC 801-2<br />8 kV on air IEC 801-2 |
Resistance to electromagnetic fields | 9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3 | Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) |
Ambient Air Temperature for Storage | -40…185 °F (-40…85 °C) | Relative Humidity | 95 % without condensation |
Operating altitude | <= 16404.2 ft (5000 m) |
Specifications may be subject to change without notice
