Product Model
140DDO36400
Selling Points
- 1High-Density Configuration: 96 discrete output channels organized into six groups of 16 for extensive control options.
- 2Negative Logic Operation: Compatible with various industrial control systems using negative logic (sink).
- 3Surge Current Protection: Equipped with surge current protection mechanisms to ensure safety and integrity of connected devices.
- 4CE Compliance: Meets European safety and quality standards, ensuring consistent performance in industrial environments.
- 5Efficient Power Management: Operates with a power dissipation of 7 W and a bus current requirement of <= 250 mA, minimizing energy consumption and reducing operating costs.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon Quantum automation platform | Product or Component Type | Dc discrete output module |
Discrete output number | 96 | Group of channels | 6 groups of 16 |
Discrete output logic | Negative logic (sink) | Addressing requirement | 6 output words |
Discrete output voltage | 24 V DC | Output voltage limits | 19.2...30 V |
Maximum voltage drop | <0.4 V 0.5 A | Maximum load current | <= 0.5 A each point<br /><= 19.2 A per module<br /><= 3.2 A each group |
Surge current | 2 A | Response Time | <= 0.1 ms at state 0 to state 1<br /><= 0.1 ms at state 1 to state 0 |
Maximum leakage current | 1 mA 24 V | Short-circuit protection | With |
Output overload protection | With | Load inductance | Inductance(H) = 0.5/((current(A))² x (switching frequency(Hz))) 0.5...4 Hz |
Fault indication | Fault sensing<br />Fault point<br />Loss of field power<br />Fault reporting | Isolation between channels and bus | 500 Vrms DC for 1 minute |
Power dissipation | 7 W | marking | CE |
Local signalling | for bus communication is present (Active) 1 LED (green)<br /> for external fault detected (F) 1 LED (red)<br /> for input status 96 LEDs (green) | Bus current requirement | 250 mA |
Module format | Standard | Net Weight | 0.99 lb(US) (0.45 kg) |
Product Certifications | C-tick<br />RMRS<br />GOST<br />FM Class 1 Division 2 | Standards | CSA C22.2 No 142<br />UL 508 |
Resistance to electrostatic discharge | 4 kV contact IEC 801-2<br />8 kV on air IEC 801-2 | Resistance to electromagnetic fields | 9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3 |
Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) | Ambient Air Temperature for Storage | -40…185 °F (-40…85 °C) |
Relative Humidity | 95 % without condensation | Operating altitude | <= 16404.2 ft (5000 m) |
Specifications may be subject to change without notice
