Product Model
ATV71H075M3T1
Selling Points
- 1High Efficiency: The ATV71H075M3T1 offers high efficiency with its flux vector control (FVC) technology, ensuring optimal performance in various applications.
- 2Compact Design: This drive features a compact design, making it easy to integrate into existing systems without taking up too much space.
- 3EMC Filter Integrated: Equipped with an integrated EMC filter, the ATV71H075M3T1 minimizes electromagnetic interference, ensuring smooth operation in noisy environments.
- 4CANopen and Modbus Compatibility: Compatible with CANopen and Modbus protocols, this drive can seamlessly integrate into various control systems.
- 5Robust Construction: Built with robust materials and designed for harsh environments, the ATV71H075M3T1 provides reliable operation over extended periods.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Asynchronous motor control profile | Constant torque standard | Device short name | ATV71 |
Range of Product | Altivar 71 | Line Rated Current | 4.8 A<br />3 A 1 phase |
Cable entry | Type 1 conduit entry outdoor | communication port protocol | CANopen<br />Modbus |
Input voltage | 208/240 V AC | Keypad Type | LCD keypad |
Maximum Horse Power Rating | 1 hp<br />0.5 hp, 1 phase | Motor power kW | 0.75 kW<br />0.37 kW, 1 phase |
Phase | 3 phase output<br />1 phase input<br />3 phase | Output voltage | <= rated supply voltage |
EMC filter | Class A EMC filter integrated | IP Degree of Protection | IP20 |
NEMA Degree of Protection | No enclosure rating (open device) | Protective treatment | None |
Specifications may be subject to change without notice
