Product Model

BMXNOM0200H

Manufacturer

schneider

Category

PLC/PAC and Controllers

Product ID

29649

In Stock
Last updated: 2025/4/19
View Specifications
schneider BMXNOM0200H

Selling Points

  • 1Built for harsh chemical environments with an extended temperature range from -25°C to +70°C.
  • 2Features 2 RS-485/232 ports in Modbus and character mode for versatile communication.
  • 3Operates at 80mA with an internal power supply via rack, ideal for energy-efficient applications.
  • 4Ensures protection against solid objects larger than 12.5 mm in diameter, suitable for standard and severe environment applications.
  • 5Meets UL 508, EN 61131-2, EN 61000-6-4, and other international standards for safety and performance.
Product Details
BMXNOM0200H
schneider

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Range of Product
Modicon X80
Product or Component Type
Serial links module
Product Specific Application
For severe environments
Concept
Serial link
Integrated connection type
RS232 RJ45 115.2 kbit/s 8 wires<br />RS485 RJ45 57.6 kbit/s 1 twisted pair
Protective treatment
Conformal coating
Supply
Internal power supply via rack
marking
CE
Local signalling
for module fault (ERR) 1 LED (red)<br /> for module running (RUN) 1 LED (green)<br /> for activity on the serial link (SER COM 0) 1 LED (green)<br /> for activity on the serial link (SER COM 1) 1 LED (green)
Current consumption
80 mA 24 V DC
Module format
Standard
Net Weight
0.51 lb(US) (0.23 kg)
Ambient Air Temperature for Operation
-13…158 °F (-25…70 °C)
Relative Humidity
10…95 % without condensation
IP Degree of Protection
IP20
Directives
2014/35/EU - low voltage directive<br />2014/30/EU - electromagnetic compatibility<br />2014/34/EU - ATEX directive
Product certifications
CE<br />UL<br />CSA<br />RCM<br />EAC<br />Merchant Navy<br />ATEX zone 2/22<br />IECEx zone 2/22
Standards
EN/IEC 61131-2<br />EN/IEC 61010-2-201<br />UL 61010-2-201<br />CSA C22.2 No 61010-2-201<br />IACS E10<br />EN/IEC 61000-6-5, interface type 1 and type 2<br />EN/IEC 61850-3, location G<br />EN/IEC 60079-0
Environmental characteristic
Gas resistant class Gx ISA S71.04<br />Gas resistant class 3C4 IEC 60721-3-3<br />Dust resistant class 3S4 IEC 60721-3-3<br />Sand resistant class 3S4 IEC 60721-3-3<br />Salt resistant level 2 IEC 68252<br />Mold growth resistant class 3B2 IEC 60721-3-3<br />Fungal spore resistant class 3B2 IEC 60721-3-3<br />Hazardous location class I division 2

Specifications may be subject to change without notice
