Product Model
GV2G345
Selling Points
- 1High Current Capacity: Handles 63A of current for reliable power distribution.
- 2Multiple Tap-Offs: Features 3 tap-offs for flexible wiring configurations.
- 3Compact Design: Measured at 135mm length with a 45mm pitch.
- 4Insulated for Safety: Insulated to ensure safe operation in electrical systems.
- 5Compatible with TeSys Devices: Designed for use with TeSys GV2, TeSys D, TeSys K, and TeSys U motor circuit breakers.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range | Linergy | Product name | FT |
Device short name | GV2G | Product or Component Type | Comb busbar |
accessory / separate part category | Connection accessory | Poles description | 3P |
Range compatibility | TeSys GV2<br />TeSys K<br />TeSys U | Number of tap-offs | 3 |
[Ith] conventional free air thermal current | 63 A | Connection pitch | 1.8 in (45 mm) |
Mounting Location | On terminal | [Ui] Rated Insulation Voltage | 690 V |
Length | 5.3 in (134 mm) | Net Weight | 0.128 lb(US) (0.058 kg) |
Specifications may be subject to change without notice
