Product Model
HMIDM6700WC
Selling Points
- 1High-Resolution Display: Features FWXGA resolution (1366 x 768 pixels) for clear and detailed visuals.
- 2Multi-Touch Technology: Equipped with PCAP multi-touch technology for precise and intuitive interaction.
- 3Robust Environmental Performance: Designed for indoor use with IP66F and IP67F protection, suitable for harsh environments.
- 4Energy Efficiency: Low power consumption (74W typical with advanced box) and long backlight lifespan (50,000 hours).
- 5Versatile Installation Options: Compatible with VESA mounting and direct mounting, offering flexibility in installation configurations.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Harmony P6 | Product or Component Type | Touch panel screen |
Display size | 15.6 inch | Aspect ratio | 16:9 |
Display colour | 16 million colours | Pixel resolution | 1366 x 768 |
Inrush current | 30 A | Device mounting | Panel mounting<br />Direct mounting VESA |
cut-out dimensions | 394 (+ 1/- 0) x 250 (+ 1/- 0) mm | Width | 16.06 in (408 mm) |
Height | 10.4 in (264 mm) | Net Weight | 8.8 lb(US) (4.0 kg) |
Product certifications | RCM<br />KC<br />UKCA<br />DNV (DC model without HDD/fan/ EtherCAT card/22" wide display with expansion slot)<br />ATEX zone 22 dust (DC model, front USB cover must be locked with screw)<br />ATEX zone 2 (DC model, front USB cover must be locked with screw)<br />CULus Class 1 Division 2 (without DIO option)<br />IECEx zone 2 (DC model, front USB cover must be locked with screw)<br />IECEx zone 22 (DC model, front USB cover must be locked with screw) | Ambient air temperature for operation | 32…140 °F (0…60 °C) |
Pollution degree | 2 | Operating altitude | 6561.68 ft (2000 m) |
Shock resistance | 147 m/s² IEC 61131-2<br />147 m/s² 3 shocks in each direction X, Y and Z |
Specifications may be subject to change without notice
