schneider HMIDM7421

Selling Points

  • 115-inch LED color TFT LCD display with 2048 x 2048 touchscreen resolution.
  • 2Single-touch analog resistive panel for precise interaction.
  • 3IP66 and NEMA 4X rated for durability in harsh environments.
  • 4Operates with water on screen, suitable for industrial use.
  • 5Certified by ATEX, EAC, and other international standards for reliability and safety.
Product Details
HMIDM7421
schneider

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Range of Product
Harmony iPC
Product or Component Type
Flat screen
Terminal type
Touchscreen display
Device mounting
Flush
Product Compatibility
Modular Box PC
View angle horizontal x vertical
140 x 115°
Contrast Ratio
500:1
Pixel resolution
2048 x 2048
Touchscreen resolution
2048 x 2048
Display resolution
1024 x 768 pixels XGA
Display size
15 inch
Aspect ratio
4:3
Display type
LED<br />Colour TFT LCD
Display colour
16777216 colors
Luminance
27.9 fc (300 cd/m²)
Backlight lifespan
50000 hours 77 °F (25 °C)
Touch panel
Single touch analogue resistive
Integrated connection type
USB 2.0 type A
Function Available
Operate with water on screen
[Us] rated supply voltage
24 V DC power supply<br />100...240 V AC power supply
Supply voltage limits
18…36 V
Inrush current
8.9 A
Power consumption in W
53.04 W Box PC HMIBMP)<br />48.04 W Box PC HMIBMU)
Local signalling
Status LED
Depth
Enclosure : 1.1 in (28 mm)<br />0.3 in (7 mm)
Height
11.4 in (290 mm)
Width
15.4 in (390.7 mm)
Net Weight
9.3 lb(US) (4.2 kg)
Standards
Class I division 2 CSA C22.2 No 213<br /> CSA C22.2 No 142<br /> UL 6110-2-201<br />Class I division 2 ANSI/ISA 12-12-01
Product certifications
EAC<br />ATEX<br />C-tick<br />IEC-Ex<br />Marine GL Bridge<br />CE
IP degree of protection
IP66
NEMA degree of protection
NEMA 4X
Pollution degree
2
Ambient air temperature for storage
-22…158 °F (-30…70 °C)
Relative Humidity
10…95 % non-condensing
Ambient air temperature for operation
32…131 °F (0…55 °C)
Operating altitude
6561.68 ft (2000 m)
Vibration resistance
1 gn 5…500 Hz) HDD<br />2 gn 5…500 Hz) SSD<br />2 gn 5…500 Hz) Cfast card

Specifications may be subject to change without notice
