Product Model
RM35TF30SP01
Selling Points
- 1Advanced 3-Phase Control: Manage 3-phase supply with precision.
- 2Phase Sequence & Failure Detection: Ensure correct phase sequence and detect failures.
- 3Voltage Monitoring: Monitor voltage levels in three-phase systems.
- 4Adjustable Time Delay: Set time delays from 0.1 to 10 seconds.
- 5Durable Design: Built with self-extinguishing plastic for long-lasting performance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Harmony Relay | Relay Type | Multifunction control relay |
Product or Component Type | Modular measurement and control relays | Product Specific Application | For 3-phase supply |
Relay name | RM35TF | Relay monitored parameters | Phase sequence<br />Asymmetry<br />Undervoltage and overvoltage in window mode<br />Phase failure detection |
time delay | Adjustable 0.1...10 s, +/- 10 % of the full scale value | Output contacts | 2 C/O |
Nominal output current | 5 A | Supply voltage limits | 194…528 V AC, 3 phase |
Reset time | 1500 ms at 480 V | Maximum switching voltage | 250 V AC<br />250 V DC |
Switching capacity in VA | 1250 VA | Minimum switching current | 10 mA 5 V DC |
Maximum switching current | 5 A AC<br />5 A DC | Control circuit voltage limits | - 12 % + 10 % Un |
Power consumption in VA | 0…22 VA 400 V AC 50 Hz | Voltage detection threshold | < 194 V |
Control circuit frequency | 50...60 Hz +/- 10 % | Hysteresis | 2 % |
delay at power up | 650 ms | Maximum measuring cycle | 140 ms measurement cycle as true rms value |
Threshold adjustment voltage | 2...20 % of Un selected<br />-12...-2 % in the range 220 V AC<br />+2...+10 % in the range 480 V AC<br />-20...-2 % in the range 380...480 V AC<br />+2...+20 % in the range 220...440 V AC | Voltage range | 220...480 V phase to phase |
Adjustment of asymmetry threshold | 5...15 % of Un selected | Repeat accuracy | 0.3 % time delay<br />0.5 % input and measurement circuit |
Measurement error | < 1 % over the whole range with voltage variation<br />0.05 %/°C with temperature variation | Response time | < 200 ms (in the event of a fault) |
Insulation resistance | > 500 MOhm 500 V DC IEC 60255-5<br />> 500 MOhm 500 V DC IEC 60664-1 | [Ui] rated insulation voltage | 400 V IEC 60664-1 |
Supply frequency | 50/60 Hz +/- 10 % | Operating position | Any position without derating |
Connections - terminals | Screw terminals, 1 x 0.5...1 x 4 mm² AWG 20...AWG 11) solid without cable end<br />Screw terminals, 2 x 0.5...2 x 2.5 mm² AWG 20...AWG 14) solid without cable end<br />Screw terminals, 1 x 0.2...1 x 2.5 mm² AWG 24...AWG 12) flexible with cable end<br />Screw terminals, 2 x 0.2...2 x 1.5 mm² AWG 24...AWG 16) flexible with cable end | Tightening torque | 5.3…8.9 lbf.in (0.6…1 N.m) IEC 60947-1 |
Housing material | Self-extinguishing plastic | Local signalling | for power ON LED (green)<br /> for relay ON LED (yellow)<br /> for fault LED (yellow) |
Mounting support | 35 mm symmetrical DIN rail conforming to EN/IEC 60715 | Electrical durability | 100000 cycles |
Mechanical durability | 30000000 cycles | Operating rate | <= 360 operations/hour full load |
Utilisation category | AC-12 IEC 60947-5-1<br />AC-13 IEC 60947-5-1<br />AC-14 IEC 60947-5-1<br />AC-15 IEC 60947-5-1<br />DC-12 IEC 60947-5-1<br />DC-13 IEC 60947-5-1 | Safety reliability data | B10d = 360000<br />MTTFd = 399.5 years |
Width | 1.4 in (35 mm) | Net Weight | 0.29 lb(US) (0.13 kg) |
Electromagnetic compatibility | Emission standard for industrial environments conforming to EN/IEC 61000-6-4<br />Emission standard for residential, commercial and light-industrial environments conforming to EN/IEC 61000-6-3<br />Immunity for industrial environments conforming to EN/IEC 61000-6-2 | Standards | EN/IEC 60255-1 |
Product Certifications | CSA<br />C-tick<br />GL<br />GOST<br />UL | marking | CE |
Directives | 89/336/EEC - electromagnetic compatibility<br />73/23/EEC - low voltage directive | Ambient Air Temperature for Storage | -40…158 °F (-40…70 °C) |
Ambient air temperature for operation | -4…122 °F (-20…50 °C) | Relative humidity | 95 % 131 °F (55 °C) IEC 60068-2-30 |
Vibration resistance | 0.35 mm 5…57.6 Hz)IEC 60068-2-6<br />1 gn 57.6…150 Hz)IEC 60255-21-1 | Shock resistance | 15 gn 11 ms IEC 60255-21-1 |
IP degree of protection | IP20 IEC 60529 terminals)<br />IP30 IEC 60529 casing) | Pollution degree | 3 IEC 60664-1 |
Overvoltage category | III IEC 60664-1 | Dielectric test voltage | 2 kV AC 50 Hz, 1 min |
Non-dissipating shock wave | 4 kV |
Specifications may be subject to change without notice
