Product Model
TM168BEVCMEM
Selling Points
- 1High-performance EV charging with up to 60 kW power output.
- 2Advanced thermal management for optimal performance in various environments.
- 3Integrated smart charging technology for efficient energy usage.
- 4Compact and durable design suitable for both indoor and outdoor applications.
- 5Compatible with a wide range of EV models, ensuring seamless integration.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon M168 logic controller | Product or Component Type | Application-specific expansion module |
Product Specific Application | Control of electronic expansion valve | Connector Type | Without connector |
Discrete input number | 2 no isolated digital input<br />1 isolated digital input | Contacts usage | Volt-free contacts |
Discrete input voltage | 100...240 V | Discrete input voltage type | AC/DC |
Sensor power supply | 12 V AC/DC | Voltage state 1 guaranteed | 100 V auxiliary input |
Analogue input number | 2<br />1 | Analogue input type | Voltage 0...10 V or 0...5 V ratio<br />Current 0...20 mA/4...20 mA<br />Temperature probe -100...400 °C Pt 1000<br />Temperature probe -50...+120 °C NTC 10k |
Discrete output voltage | 250 V AC | Discrete output current | 5000 mA |
Electrical durability | 100000 cycles 24 V AC<br />100000 cycles 24...37 V DC | Mounting Support | 35 mm symmetrical DIN rail |
Width | 2.8 in (71 mm) | Height | 5.04 in (128 mm) |
Depth | 2.4 in (60 mm) | Net Weight | 0.379 lb(US) (0.172 kg) |
Standards | EN 60730-1<br />EN 61000-6-1<br />EN 61000-6-3<br />UL 60730<br />2006/95/EEC | marking | CE<br />UL |
Ambient Air Temperature for Operation | 14…140 °F (-10…60 °C) | Ambient Air Temperature for Storage | -13…140 °F (-25…60 °C) |
Relative humidity | 10…90 % without condensation | IP Degree of Protection | IP20 |
Pollution degree | 2 | Overvoltage category | III |
Operating altitude | 0...6561.68 ft (0...2000 m) |
Specifications may be subject to change without notice
