Product Model
TM171ARS485
Selling Points
- 1High power density for compact designs.
- 2Wide input voltage range for flexibility.
- 3Low noise and high reliability.
- 4Built-in protection features for safety.
- 5Compatible with various industrial applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon M171 | Product or Component Type | Communication module |
communication port protocol | RS485<br />BACnet MS/TP<br />Modbus RTU | Integrated connection type | RS485 wire crimp - twisted pair |
Adjustment | Pitch 3.81 mm | Electrical connection | removable screw terminal block |
Physical interface | 90° insertion - 0.004 in² (2.5 mm²) cable | Supply | Via base board EVD/EVC |
Product Compatibility | Logic controller M172 performance<br />Logic controller M171 performance | Net Weight | 0.170 lb(US) (0.077 kg) |
Product Certifications | cURus<br />CSA<br />EAC<br />CE | marking | CE |
IP Degree of Protection | IP20 | Ambient Air Temperature for Operation | 14…131 °F (-10…55 °C) |
Ambient Air Temperature for Storage | -4…185 °F (-20…85 °C) | Relative Humidity | 10…90 % without condensation |
Specifications may be subject to change without notice
