Product Model
TM171DGRP
Selling Points
- 1High-capacity power distribution for demanding environments.
- 2Robust design with durable components for extended lifespan.
- 3Easy installation with intuitive interface and modular design.
- 4Enhanced safety features including arc fault detection and ground fault protection.
- 5Compatible with a wide range of applications including industrial and commercial settings.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon M171 | Product or Component Type | Display module |
Display colour | Monochrome | Supply | External source |
Display Type | Backlit LCD | Number of key | 5 |
Display Resolution | 240 x 140 pixels | Color | Gray |
[Us] rated supply voltage | 12 V AC<br />24 V AC<br />24 V DC | Power consumption in W | 0 W<br />5 W |
marking | CE | Realtime clock | With |
Local signalling | 1 LED (green)<br /> 1 LED (yellow)<br /> 1 LED (red) | Product Compatibility | Logic controller M171 performance |
Height | 6.3 in (160 mm) | Width | 3.5 in (90 mm) |
Depth | 1.06 in (27 mm) | Net Weight | 0.434 lb(US) (0.197 kg) |
Product Certifications | cURus |
Specifications may be subject to change without notice
