Product Model
TM171DLCD2U
Selling Points
- 1High-resolution 17-inch LCD display with vibrant colors.
- 2Robust construction for durability in harsh environments.
- 3Wide viewing angles for clear visibility from any position.
- 4Integrated with Schneider's advanced control systems for seamless integration.
- 5Energy-efficient design to reduce power consumption and costs.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon M171 | Product or Component Type | Display module |
Display colour | Monochrome | Supply | External source |
Display Type | LCD screen | Number of key | 8 |
Color | Gray | [Us] rated supply voltage | 12 V DC |
Power consumption in W | 5 W<br />0 W | marking | CE |
Realtime clock | With | Local signalling | LCD display |
Product Compatibility | Logic controller M171 optimized | Height | 6.3 in (160 mm) |
Width | 3.8 in (96 mm) | Depth | 0.4 in (10 mm) |
Net Weight | 0.037 lb(US) (0.017 kg) | Standards | IEC 61000-4-5<br />IEC 61000-4-3<br />IEC 61000-4-2<br />IEC 60068-2-27<br />IEC 60730-1<br />IEC 60068-2-6 Fc<br />UL 60730-1<br />UL 60730-2-9<br />IEC 61000-4-4<br />CAN/CSA-E60730-1<br />IEC 61000-4-11<br />IEC 61000-4-6<br />CSA E60730-2-9<br />IEC 60730-2-9<br />UL94 (material V0) |
Product Certifications | CSA<br />EAC<br />RCM<br />CE<br />cURus | IP degree of protection | IP40 front face: |
Specifications may be subject to change without notice
