Product Model
TM171OF22R
Selling Points
- 1High-performance power supply with 1700W output.
- 2Compact design for easy integration into industrial systems.
- 3Wide input voltage range for adaptability in various environments.
- 4Built-in protection features for enhanced system reliability.
- 5Meets international safety standards for industrial use.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon M171/M172 | Product or Component Type | Controller |
Product Specific Application | HVAC and pumping solution | Variant | Programmable |
Total inputs/outputs | 22 | Discrete input number | 6 |
Discrete output number | 1 open collector<br />3 relay outputs SPST with same common<br />2 relay outputs SPST with independent common | Discrete output current | 2 A relay |
Analogue input number | 2 configurable<br />3 analog input NTC | Analogue output number | 3 voltage 0...10 V<br />2 PWM/PPM 20 kHz, 12 V, 35 mA |
Number of port | 1 LAN expansion bus | Input/output number | 5 analog output<br />6 digital input<br />5 analog input<br />6 digital output |
Discrete input logic | Sink or source (positive/negative) | Contacts usage | Volt-free contacts |
Analogue input type | voltage 0...5 V ratiometric)<br /> voltage 0...10 V<br />NTC temperature probe - 50...100 °C 0.1 °C<br /> current 0...20 mA/4...20 mA<br /> voltage 0...1 V | Sensor power supply | 12 V DC 85 mA<br />5 V DC 20 mA |
[Us] rated supply voltage | 12...24 V +/- 20 % AC/DC<br />24 V +/- 20 % DC | Power consumption in W | 18 W 24...48 V AC/DC |
Realtime clock | Built-in clock at 14…131 °F (-10…55 °C) | Display type | Without Display |
Overvoltage category | II | Local signalling | for programmable 1 LED (red)<br /> for programmable 1 LED (yellow)<br /> for programmable 1 LED (green) |
Mounting Support | DIN rail | Width | 5.5 in (140 mm) |
Height | 4.3 in (110 mm) | Depth | 2.4 in (61.6 mm) |
Net Weight | 0.849 lb(US) (0.385 kg) | Directives | 86/188/EEC - physical agents (noise) directive<br />2006/95/EC - low voltage directive |
Standards | EN/IEC 60730 | Product Certifications | CE<br />cURus<br />CSA<br />EAC |
Ambient air temperature for operation | 14…131 °F (-10…55 °C) UL 60730-1 | Ambient Air Temperature for Storage | -40…185 °F (-40…85 °C) |
Relative humidity | 10…90 % non-condensing | IP degree of protection | IP20 |
Pollution degree | 2 |
Specifications may be subject to change without notice
