Product Model
TM171PFE03HR
Selling Points
- 1High reliability and durability for long-lasting performance.
- 2Compact design for easy installation in tight spaces.
- 3Advanced safety features including arc fault detection and ground fault protection.
- 4High current capacity up to 100A for heavy-duty applications.
- 5Compliant with international safety standards for global use.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon M171/M172 | Product or Component Type | Programmable controllers |
Product Specific Application | HVAC and pumping solution | Variant | Programmable |
Total inputs/outputs | 3 | Analogue input number | 1 analog input NTC board)<br />1 analog input NTC<br />1 relative humidity sensor board) |
Number of port | 1 CAN port - screw terminal block<br />1 Ethernet - RJ45 Modbus TCP and BACnet IP with webserver)<br />1 RS485 - screw terminal block Modbus serial link or BACnet MS/TP)<br />1 | Input/output number | 3 analog input |
Analogue input type | NTC temperature probe - 50...110 °C 0.1 °C extended)<br />NTC temperature probe - 40...150 °C 0.1 °C<br /> humidity probe 0...100 % RH 0.01 % RH | [Us] rated supply voltage | 24 V ±10% AC<br />48 V DC |
Power consumption in W | 24 VA 24 V AC<br />15 W 20...38 V DC | Realtime clock | Without clock at -4…149 °F (-20…65 °C) |
Display type | Without Display | Overvoltage category | II |
Local signalling | without | Mounting Support | Panel mounting with accessory<br />DIN rail |
Width | 2.8 in (72 mm) | Height | 4.3 in (110 mm) |
Depth | 2.4 in (60.5 mm) | Net Weight | 0.49 lb(US) (0.22 kg) |
Standards | EN/IEC 60730 | Product Certifications | CE<br />EAC<br />CSA<br />cURus<br />RCM |
Ambient air temperature for operation | -4…149 °F (-20…65 °C) UL 60730-1 | Ambient Air Temperature for Storage | -4…185 °F (-20…85 °C) |
Relative humidity | 10…90 % non-condensing | IP degree of protection | IP20 |
Pollution degree | 2 |
Specifications may be subject to change without notice
