Product Model
TM172DCLFW
Selling Points
- 1High reliability and durability for long-lasting performance.
- 2Compact design for easy installation in tight spaces.
- 3Advanced safety features including arc fault detection and ground fault protection.
- 4Compatible with a wide range of applications including industrial and commercial settings.
- 5Easy-to-use interface with clear indicators for quick monitoring and troubleshooting.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon M171/M172 | Product or Component Type | Display module |
Supply | External source | Display Type | Colour touchscreen<br />LCD display |
Display Resolution | 320 x 240 pixels | Color | White |
[Us] rated supply voltage | 24 V AC/DC | Power consumption in W | 3.2 VA<br />1.3 W |
Overvoltage category | II | Product Compatibility | Logic controller M171<br />Logic controller M172 |
Height | 3.8 in (96 mm) | Width | 5.3 in (134 mm) |
Depth | 1.4 in (35 mm) | Net Weight | 0.386 lb(US) (0.175 kg) |
Directives | 2014/30/EU - electromagnetic compatibility | Standards | IEC 61000-4-2<br />IEC 60730-1<br />IEC 61000-4-5<br />CAN/CSA-E60730-1<br />IEC 61000-4-11<br />UL 60730-1<br />IEC 61000-4-4<br />IEC 61000-4-6<br />CSA E60730-2-9<br />UL 60730-2-9<br />IEC 61000-4-3<br />IEC 60730-2-9 |
Product Certifications | cURus<br />RCM<br />CE<br />CSA<br />EAC | Ambient Air Temperature for Operation | -4…140 °F (-20…60 °C) |
Ambient Air Temperature for Storage | -22…140 °F (-30…60 °C) | IP degree of protection | IP65 front panel: |
Pollution degree | 2 |
Specifications may be subject to change without notice
