Product Model
TM221C24R
Selling Points
- 1High-performance power supply module designed for industrial use.
- 2Compact and reliable design for space-saving installations.
- 324V output voltage with high current capacity.
- 4Built with durable components for long-lasting operation.
- 5Compatible with a wide range of industrial control systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon M221 | Product or Component Type | Logic controller |
[Us] rated supply voltage | 100...240 V AC | Discrete input number | 14, discrete input IEC 61131-2 Type 1 |
Analogue input number | 2 0...10 V | Discrete output type | Relay normally open |
Discrete output number | 10 relay | Discrete output voltage | 5...125 V DC<br />5...250 V AC |
Discrete output current | 2 A | Discrete I/O number | 24 |
Maximum number of I/O expansion module | 7 (local I/O-Architecture)<br />14 (remote I/O-Architecture) | Supply voltage limits | 85…264 V |
Network Frequency | 50/60 Hz | Inrush current | 40 A |
Maximum power consumption in VA | 55 VA 100...240 V with max number of I/O expansion module<br />32 VA 100...240 V without I/O expansion module | Power supply output current | 0.52 A 5 V expansion bus<br />0.16 A 24 V expansion bus |
Discrete input logic | Sink or source (positive/negative) | Discrete input voltage | 24 V |
Discrete input voltage type | DC | Analogue input resolution | 10 bits |
LSB value | 10 mV | Conversion time | 1 ms per channel + 1 controller cycle time analog input |
Permitted overload on inputs | +/- 30 V DC 5 min maximum)analog input<br />+/- 13 V DC permanent)analog input | Voltage state 1 guaranteed | >= 15 V input |
Voltage state 0 guaranteed | <= 5 V input | Discrete input current | 7 mA discrete input<br />5 mA fast input |
Input impedance | 3.4 kOhm discrete input<br />100 kOhm analog input<br />4.9 kOhm fast input | Response time | 35 µs turn-off, I2...I5 input<br />10 ms turn-on output<br />10 ms turn-off output<br />5 µs turn-on, I0, I1, I6, I7 fast input<br />35 µs turn-on, other terminals input<br />5 µs turn-off, I0, I1, I6, I7 fast input<br />100 µs turn-off, other terminals input |
Configurable filtering time | 0 ms input<br />3 ms input<br />12 ms input | Output voltage limits | 125 V DC<br />277 V AC |
Maximum current per output common | 4 A COM 2<br />7 A COM 0<br />7 A COM 1 | Absolute accuracy error | +/- 1 % of full scale analog input |
Electrical durability | 100000 cycles AC-12, 120 V, 240 VA, resistive<br />100000 cycles AC-12, 240 V, 480 VA, resistive<br />300000 cycles AC-12, 120 V, 80 VA, resistive<br />300000 cycles AC-12, 240 V, 160 VA, resistive<br />100000 cycles AC-15, cos phi = 0.35, 120 V, 60 VA, inductive<br />100000 cycles AC-15, cos phi = 0.35, 240 V, 120 VA, inductive<br />300000 cycles AC-15, cos phi = 0.35, 120 V, 18 VA, inductive<br />300000 cycles AC-15, cos phi = 0.35, 240 V, 36 VA, inductive<br />100000 cycles AC-14, cos phi = 0.7, 120 V, 120 VA, inductive<br />100000 cycles AC-14, cos phi = 0.7, 240 V, 240 VA, inductive<br />300000 cycles AC-14, cos phi = 0.7, 120 V, 36 VA, inductive<br />300000 cycles AC-14, cos phi = 0.7, 240 V, 72 VA, inductive<br />100000 cycles DC-12, 24 V, 48 W, resistive<br />300000 cycles DC-12, 24 V, 16 W, resistive<br />100000 cycles DC-13, 24 V, 24 W, inductive (L/R = 7 ms)<br />300000 cycles DC-13, 24 V, 7.2 W, inductive (L/R = 7 ms) | Switching frequency | 20 switching operations/minute with maximum load |
Mechanical durability | 20000000 cycles relay output | Minimum load | 1 mA 5 V DC relay output |
Protection type | Without protection 5 A | Reset time | 1 s |
Memory capacity | 256 kB user application and data RAM 10000 instructions<br />256 kB internal variables RAM | Data backed up | 256 kB built-in flash memory backup of application and data |
Data storage equipment | 2 GB SD card optional) | Battery type | BR2032 or CR2032X lithium non-rechargeable |
Backup time | 1 year 77 °F (25 °C) by interruption of power supply) | Execution time for 1 KInstruction | 0.3 ms event and periodic task |
Execution time per instruction | 0.2 µs Boolean | Exct time for event task | 60 µs response time |
Maximum size of object areas | 255 %C counters<br />8000 %MW memory words<br />512 %M memory bits<br />512 %KW constant words<br />255 %TM timers | Realtime clock | With |
Clock drift | <= 30 s/month 77 °F (25 °C) | Regulation loop | Adjustable PID regulator up to 14 simultaneous loops |
Counting input number | 4 fast input (HSC mode) 100 kHz 32 bits | counter function | A/B<br />Single phase<br />Pulse/direction |
Integrated connection type | USB port mini B USB 2.0<br />Non isolated serial link serial 1 RJ45 RS485<br />Non isolated serial link serial 2 RJ45 RS232/RS485 | Supply | Serial)serial link supply 5 V, <200 mA |
Transmission rate | 1.2...115.2 kbit/s (115.2 kbit/s by default) 49.2 ft (15 m) RS485<br />1.2...115.2 kbit/s (115.2 kbit/s by default) 9.8 ft (3 m) RS232<br />480 Mbit/s USB | Communication port protocol | USB port USB - SoMachine-Network<br />Non isolated serial link Modbus master/slave - RTU/ASCII or SoMachine-Network |
Local signalling | for PWR 1 LED (green)<br /> for RUN 1 LED (green)<br /> for module error (ERR) 1 LED (red)<br /> for SD card access (SD) 1 LED (green)<br /> for BAT 1 LED (red)<br /> for SL1 1 LED (green)<br /> for SL2 1 LED (green)<br /> for I/O state 1 LED per channel (green) | Electrical connection | removable screw terminal block for inputs<br /> removable screw terminal block for outputs<br /> terminal block, 3 for connecting the 24 V DC power supply<br /> connector, 4 for analogue inputs<br />Mini B USB 2.0 connector for a programming terminal |
Maximum cable distance between devices | Shielded cable <32.8 ft (10 m) fast input<br />Unshielded cable <98.4 ft (30 m) output<br />Unshielded cable <98.4 ft (30 m) digital input<br />Unshielded cable <3.3 ft (1 m) analog input | Insulation | Between input and internal logic 500 V AC<br />Non-insulated between analogue input and internal logic<br />Non-insulated between analogue inputs<br />Between supply and ground 1500 V AC<br />Between sensor power supply and ground 500 V AC<br />Between input and ground 500 V AC<br />Between output and ground 1500 V AC<br />Between supply and internal logic 2300 V AC<br />Between sensor power supply and internal logic 500 V AC<br />Between output and internal logic 2300 V AC<br />Between Ethernet terminal and internal logic 500 V AC<br />Between supply and sensor power supply 2300 V AC |
Marking | CE | Sensor power supply | 24 V DC 250 mA supplied by the controller |
Mounting support | Top hat type TH35-15 rail IEC 60715<br />Top hat type TH35-7.5 rail IEC 60715<br /> plate or panel with fixing kit | Height | 3.5 in (90 mm) |
Depth | 2.8 in (70 mm) | Width | 4.3 in (110 mm) |
Net Weight | 0.871 lb(US) (0.395 kg) | Standards | IEC 61131-2<br />UL 508<br />CAN/CSA C22.2 No. 213<br />IACS E10<br />ANSI/ISA 12-12-01 |
Product Certifications | LR<br />ABS<br />DNV-GL<br />RCM<br />cULus<br />EAC<br />CE<br />UKCA<br />cULus HazLoc | Environmental characteristic | Ordinary and hazardous location |
Resistance to electrostatic discharge | 8 kV in air IEC 61000-4-2<br />4 kV on contact IEC 61000-4-2 | Resistance to electromagnetic fields | 9.1 V/m (10 V/m) 80 MHz...1 GHz IEC 61000-4-3<br />2.7 V/m (3 V/m) 1.4 GHz...2 GHz IEC 61000-4-3<br />0.9 V/m (1 V/m) 2...2.7 GHz IEC 61000-4-3 |
Resistance to magnetic fields | 98.4 A/m (30 A/m) 50/60 Hz IEC 61000-4-8 | Resistance to fast transients | 2 kV IEC 61000-4-4 power lines)<br />2 kV IEC 61000-4-4 relay output)<br />1 kV IEC 61000-4-4 I/O)<br />1 kV IEC 61000-4-4 Ethernet line)<br />1 kV IEC 61000-4-4 serial link) |
Surge withstand | 2 kV power lines (AC) common mode IEC 61000-4-5<br />2 kV relay output common mode IEC 61000-4-5<br />1 kV I/O common mode IEC 61000-4-5<br />1 kV shielded cable common mode IEC 61000-4-5<br />0.5 kV power lines (DC) differential mode IEC 61000-4-5<br />1 kV power lines (AC) differential mode IEC 61000-4-5<br />1 kV relay output differential mode IEC 61000-4-5<br />0.5 kV power lines (DC) common mode IEC 61000-4-5 | Resistance to conducted disturbances | 10 V 0.15...80 MHz IEC 61000-4-6<br />3 V 0.1...80 MHz Marine specification (LR, ABS, DNV, GL)<br />10 V spot frequency (2, 3, 4, 6.2, 8.2, 12.6, 16.5, 18.8, 22, 25 MHz) Marine specification (LR, ABS, DNV, GL) |
Electromagnetic emission | Conducted emissions 79 dBμV/m QP/66 dBμV/m AV power lines (AC))0.15…0.5 MHz IEC 55011<br />Conducted emissions 73 dBμV/m QP/60 dBμV/m AV power lines (AC))0.5…300 MHz IEC 55011<br />Conducted emissions 120...69 dBµV/m QP power lines)10…150 kHz IEC 55011<br />Conducted emissions 63 dBμV/m QP power lines)1.5…30 MHz IEC 55011<br />Radiated emissions 40 dBμV/m QP class A 10 m)30…230 MHz IEC 55011<br />Conducted emissions 79...63 dBμV/m QP power lines)150…1500 kHz IEC 55011<br />Radiated emissions 47 dBμV/m QP class A 10 m)200…1000 MHz IEC 55011 | Immunity to microbreaks | 10 ms |
Ambient air temperature for operation | 14…131 °F (-10…55 °C) horizontal installation)<br />14…95 °F (-10…35 °C) vertical installation) | Ambient Air Temperature for Storage | -13…158 °F (-25…70 °C) |
Relative humidity | 10…95 %, without condensation in operation)<br />10…95 %, without condensation in storage) | IP degree of protection | IP20 with protective cover in place |
Pollution degree | <= 2 | Operating altitude | 0...6561.68 ft (0...2000 m) |
Storage altitude | 0.0000000000…9842.5 ft (0…3000 m) | Vibration resistance | 3.5 mm 5…8.4 Hz symmetrical rail<br />3.5 mm 5…8.4 Hz panel mounting<br />1 gn 8.4…150 Hz symmetrical rail<br />1 gn 8.4…150 Hz panel mounting |
Shock resistance | 98 m/s² 11 ms |
Specifications may be subject to change without notice
