schneider TM3BCEIP

Selling Points

  • 1High-efficiency design for reduced energy consumption.
  • 2Compact and lightweight for easy installation in tight spaces.
  • 3Wide input voltage range for flexibility in various environments.
  • 4Built-in protection features including overvoltage, undervoltage, and overcurrent protection.
  • 5Long lifespan with minimal maintenance requirements.
Product Details
TM3BCEIP
schneider

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Range of Product
Modicon TM3
Product Compatibility
Logic controller<br />Motion controller
Product or Component Type
I/O distributed module
Product Specific Application
Bus coupler module
communication port protocol
Ethernet IP/Modbus TCP
Connector type
RJ45 2 Ethernet daisy chain isolated<br />USB device port Mini-B
Exchange mode
Half duplex, full duplex, autonegotiation
Transmission Rate
10/100 Mbit/s
Topology
Daisy chain
Port Ethernet
10/100BASE-T
Communication Network Type
Ethernet IP<br />Modbus TCP<br />IPv4 (internet protocol)
Communication Service
Ethernet/IP adapter<br />Modbus TCP/IP server<br />RSTP (Ring topology support)<br />SNMP<br />Web server<br />DHCP client<br />BOOTP<br />Address conflict detection<br />FTP server
Web services
Web server, Ethernet<br />Web server, USB
Current consumption
0.8 A 24 V DC internal supply maximum 7 expansion modules
Local signalling
1 LED green/red PWR (System Status)<br />1 LED green/red MS (Module Status)<br />1 LED green/red NS (Network Status)<br />1 LED green/red I/O status
Fixing mode
By clipping locks (rail)<br />By screws (mounting plate)
Product Certifications
CE<br />cULus<br />EAC<br />RCM<br />UKCA<br />EU-RO MR
Standards
IEC 61131-2<br />UL/CSA 61010-1<br />UL/CSA 61010-2-201
Width
1.06 in (27 mm)
Height
3.8 in (96.5 mm)
Depth
2.8 in (70 mm)
Net Weight
0.22 lb(US) (0.10 kg)
Ambient Air Temperature for Storage
-13…158 °F (-25…70 °C)
Pollution degree
2
Ambient Air Temperature for Operation
14…140 °F (-10…60 °C)
IP degree of protection
IP20 conforming to IEC/EN 61010-2-201
Relative Humidity
10…95 % non-condensing
Operating altitude
0...6561.68 ft (0...2000 m)
Storage altitude
0.0000000000…9842.5 ft (0…3000 m)
Vibration resistance
3M4 35 x 15 mm symmetrical DIN rail

Specifications may be subject to change without notice
