Product Model
TM3BCSL
Selling Points
- 1Designed for high-performance industrial applications.
- 2Ensures reliable power distribution with minimal downtime.
- 3Compact and durable design for easy installation.
- 4Meets stringent safety standards for secure operation.
- 5Optimized for energy efficiency and reduced costs.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon TM3 | Product Compatibility | Logic controller<br />Motion controller |
Product or Component Type | I/O distributed module | Product Specific Application | Bus coupler module |
communication port protocol | Modbus serial | Connector type | RJ45 2 serial link daisy chain isolated<br />USB device port Mini-B |
Exchange mode | Half duplex | Transmission Rate | 1.2...115.2 kbit/s |
Topology | Daisy chain | Communication Network Type | Modbus |
Communication Service | Modbus slave device profile | Web services | Web server, USB |
Current consumption | 0.8 A 24 V DC internal supply maximum 7 expansion modules | Local signalling | 1 LED green/red PWR (System Status)<br />1 LED green/red COM (Run)<br />1 LED green/red ERR (Error)<br />1 LED green/red I/O status |
Fixing mode | By clipping locks (rail)<br />By screws (mounting plate) | Product Certifications | CE<br />cULus<br />EAC<br />RCM<br />UKCA<br />EU-RO MR |
Standards | IEC 61131-2<br />UL/CSA 61010-1<br />UL/CSA 61010-2-201 | Width | 1.06 in (27 mm) |
Height | 3.8 in (96.5 mm) | Depth | 2.8 in (70 mm) |
Net Weight | 0.22 lb(US) (0.10 kg) | Ambient Air Temperature for Storage | -13…158 °F (-25…70 °C) |
Pollution degree | 2 | Ambient Air Temperature for Operation | 14…140 °F (-10…60 °C) |
IP degree of protection | IP20 conforming to IEC/EN 61010-2-201 | Relative Humidity | 10…95 % non-condensing |
Operating altitude | 0...6561.68 ft (0...2000 m) | Storage altitude | 0.0000000000…9842.5 ft (0…3000 m) |
Vibration resistance | 3M4 35 x 15 mm symmetrical DIN rail |
Specifications may be subject to change without notice
