Product Model
TSXDEY64D2K
Selling Points
- 1Equipped with 64 current sink-isolated discrete input channels for unparalleled flexibility and scalability in control system setups.
- 2Built with protective treatment (TC) and current sink isolation, ensuring reliability and durability in harsh industrial environments.
- 3Boasts a swift response time of 4 ms (≤ 7 ms), enabling rapid and accurate detection of input signals for precise control and monitoring.
- 4Incorporates voltage and current state guarantees, ensuring the safety of equipment and personnel in industrial settings.
- 5Minimizes power consumption with low current consumption of 155 mA at 5 V DC and 315 mA at 24 V DC, reducing operational costs and environmental impact.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon Premium Automation platform | Product or Component Type | Discrete input module |
Discrete input number | 64 current sink isolated EN/IEC 61131-2 type 1 | Discrete input voltage | 24 V DC positive |
Sensor power supply | 19…30 V | Discrete input current | 3.5 mA |
Voltage state 1 guaranteed | >= 11 V | Current state 1 guaranteed | >= 3 mA |
Voltage state 0 guaranteed | <= 5 V | Current state 0 guaranteed | <= 1.5 mA |
Input impedance | 6300 Ohm at state 1 | Response Time | 4 ms<br /><= 7 ms |
isalotion resistance | < 10 MOhm 500 V DC | Power dissipation | (1.5 W + 0.1 W x No of channels used) |
Electrical Connection | HE-10 connector | marking | CE |
Current consumption | 155 mA 5 V DC<br />315 mA 24 V DC | Module format | Standard |
Net Weight | 0.82 lb(US) (0.37 kg) | Dielectric strength | 1500 V AC 50/60 Hz |
Standards | CSA C22.2 No 142<br />73/23/EEC<br />CSA C22.2 No 213 Class I Division 2 Group B<br />CSA C22.2 No 213 Class I Division 2 Group A<br />CSA C22.2 No 213 Class I Division 2 Group C<br />UL 508<br />IEC 60664<br />CSA C22.2 No 213 Class I Division 2 Group D<br />89/336/EEC<br />93/68/EEC<br />92/31/EEC<br />EN/IEC 61131-2 | Product Certifications | LR<br />BV<br />RMRS<br />RINA<br />ABS<br />GL<br />DNV |
Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) | Ambient Air Temperature for Storage | -13…158 °F (-25…70 °C) |
Relative Humidity | 10…95 % without condensation for operation<br />5…95 % without condensation for storage | Operating altitude | 0...6561.68 ft (0...2000 m) |
Protective treatment | TC | IP Degree of Protection | IP20 |
Pollution degree | 2 |
Specifications may be subject to change without notice
